Vado Individual Elements 2 Outlet Round Concealed Thermostatic Shower Valve

Vado Individual Elements IND-ELE148D/2-BRN Details

Concealed thermostatic shower valve with 2 Outlet.
Backplate diameter: Ø196mm (Ø19.6cm).
Min-Max wall mount 70-95mm (7-9.5cm).
Optimum installation depth: 82mm (8.2cm).
2 x 3/4" female inlets.
2 x 3/4" female outlets includes 3/4” - 1/2” adaptors.
Includes mortar tile guard.

Thermostatic cartridge [V-704-34S], diverter cartridge [C-803-33X/3X].
Minimum water pressure required for shower 0.2 bar [Low Pressure].
Minimum water pressure required for bath 1.0 bar [High Pressure].
Compatible with Studfast [Optional].
Refer to the technical drawing for complete size details.
Download the User Guide and Installation Instruction PDF File from the Additional Info Section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Elements
⤷ Colour
: Brushed Nickel
⤷ Shape
: Round
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ No. of Holes Required
: 2
⤷ Min-Max Wall Mount
: 70-95

⤷ Minimum Operating Pressure (Bar)
: 0.2 - Shower / 1.0 - Bath
⤷ Handle Style
: Crosshead
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 196
⤷ Backplate Height
: 196
⤷ Number of Outlet
: 2
⤷ Product Type
: Shower Valve
⤷ Plumbing System Compatibility
: Gravity System, Pumped System, Combination Boiler, Pressurised System

Additional Info & Downloads

Download the User Guide Pdf File Download the Installation Instructions Pdf File

Customise Your Product

Studfast Brackets

The Studfast is an easy, secure and robust method of mounting thermostatic shower valves into stud walls to create a firm and trouble-free installation. Please Note: The image shown is for illustration purposes only.

None
OP-44782 - Studfast Concealed Wall Bracket + £34.48

Total: £618.76 5-7 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
