Ultra Victorian Dual Exposed Thermostatic Shower Valve - A3091E

QS-V36578 MFC CODE: A3091E


RRP: £229.00 You Save £80.15 on RRP

4.0 out of 5

5 out of 5 customers rated 80%

Review this Product


3 Working Days Approx

Shipping: FREE


Vintage styled new looking Dual Exposed Thermostatic Valve from the home of Ultra Victorian range defines traditional style valves. This valve is thermostatically controlled and is built with anti-scald device that allows hot water to be blended to a safe temperature and will shut down automatically in 1.5 seconds in case of cold water failure. It is suitable for Combi boilers and gravity fed systems.

+  Read what's included..

Download the Installation / Operating Guide Pdf File

Please Note all the measurements are in 'mm'
Colour Chrome
Warranty/Guarantee 10 Years
Material Brass
Theme Traditional
Installation Type Wall Mounted
Inlet Centres 150
Minimum Operating Pressure (Bar) 0.1
Handle Style Lever, Crosshead
WRAS Approved Yes
Depth 153
Temperature Control Thermostatic
Anti-Scald Yes
TMV2 Approved Yes
Number of Handles 2
Plumbing System Compatibility Suitable For Shower Pumps, Combi Boilers And Gravity-Fed Systems
Plumbing Option Exposed
Overall Width 196
Maximum Operating Pressure (Bar) 4
Cartridge Included Yes
Cartridge Type Valquest Cartridge
Separate Flow and Temperature Controls Yes


  • Comes in chrome finish
  • Traditional design
  • Size: Width 196mm x Depth 153mm x Height 166mm
  • Manufacturing code of this product is A3091E
  • TMV2 approved
  • Minimum water pressure recommended for smooth working is 0.1 bar [LP-Low Pressure]
  • Proudly made in Britain
  • Patented Valquest cartridge is highly resistant to calcium build up - even in hard water areas
  • Cartridge is fully reversible - in case of hot and cold water supplies comes in a wrong way, no need for re-plumbing [simply remove the cartridge turn 180° and replace]
  • Accurate flow control
  • Thermostatic control to +/- 2 degrees even if the temperature or incoming pressures fluctuate
  • Full thermal protection to prevent scalding in the event of hot or cold water failure
  • Anti-scald - In the event of hot or cold water failure, the valve will  shut down the water supply
  • Minimum flow rate is 5.5 litres per minute at 0.1 bar water pressure
  • Suitable for use with all systems: gravity fed pumped unvented high pressure or fully modulated combi-boilers
  • WRAS approved
  • 10 years of guarantee from manufacturer
  • For complete size details please refer technical drawing
  • Download installation instructions manual PDF from technical tab.
This Item is also available in:
  • Concealed - A3092C
Sizes Available
Other Sizes / Finishes / Variations Available.
QS Code Finish Size / Difference MFC Code
QS-V36577 - Concealed A3092C

Total: £148.85 3 Working Days ApproxQS Supplies

You've Selected which adds to a total of


Rate this Item.:

Questions & Answers

  Submit Your Questions 2 Questions Asked

Have a question about this item? Ask our tech team. We aim to reply within 72 hours. If you want to know get answers fast, please call us on 0116 251 0051

Hi! what is the different between Ultra AM301E and Ultra Beaumont Twin Exposed Thermostatic Valve - A3056 please. Not sure which is better or more suitable.

Answered By QS Team :
It is just the design of the shower. The A3056 has an on/off control & a thermostat control. The dual shower has the on/off and thermostat on one cartridge. Please see above for drawing.

Was this answer helpful? Yes - No

We have an AM301E thermostatic valve. Only cold water is coming through and our plumber suspects that the cartridge may be the problem. As the valve is only 2 years old and under warranty what should we do ? Regards, David Dodds

Answered By QS Team :
As the product is under warranty, we would recommend you to contact the manufacturer for the replacement cartridge.

Was this answer helpful? Yes - No
