Roper Rhodes Cranborne Exposed Thermostatic Shower Set Chrome

Roper Rhodes Cranborne SVSET125 Details

The Roper Rhodes Cranborne Exposed Thermostatic Shower Set makes a strong statement of clean lines, delicate curves and oval shapes. The set includes a Thermostatic sequential shower valve, height adjustable rigid riser rail with flow control to showerhead. Available in 2 different variants, the showerhead measures Ø200mm and is compatible with optional water and energy-saving shower flow regulators.

Suitable for low pressure water systems, the shower set includes fixings, Single function brass shower Handset and Hose and requires 0.3 bar operating water pressure for smooth working. To ensure a safe and comfortable shower experience, this set includes a thermostatic cut-off mechanism to prevent scalding in the event of the cold water feed failing.

Available in different variants - Single and Dual [Optional].
Showers and accessories with this symbol are compatible with our optional water and energy-saving shower flow regulators.
The technical drawing is available for more technical details.
Download Customer Data Sheet PDF File from the Additional Info Section.
Specification For Single Control Shower Set:.
Suitable for low-pressure water system.
Requires 0.3 bar operating water pressure.
Overall system height 1110mm (111cm), rigid riser rail.
Specification For Dual Control Shower Set:.
Supplied with fixings, Single function brass shower Handset and Hose.

Depth: 600mm (60cm).
Hose length: 1500mm (150cm).
Centre of Inlet to Outlet: 500mm (50cm).
Inlet connection: 1/2 inch BSP 15mm (1.5cm) pipe centre.
Outlet connection: 1/2 inch BSP threaded outlet.
Suitable for medium-pressure water system.
Requires 0.5 bar operating water pressure.
Flow rate (1/min): 0.5 Bar - 8.63, 1 Bar - 12.20, 2 Bar - 17.25, 3 Bar - 17.80, 4 Bar - 24.20, 5 Bar - 27.04.
The overall system height is 1237mm (123.7cm). Rigid riser rail can be cut to the height.

Please Note: Flow from valve may vary depending on accessories and domestic supply.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Theme
: Modern
⤷ Inlet Connections
: 1/2 Inch BSP
⤷ Minimum Operating Pressure (Bar)
: 0.3
⤷ Hose Included
: Yes
⤷ Hose Length
: 1500

⤷ Height
: 1237
⤷ Riser Rail & Kit Finish
: Chrome
⤷ Spray Patterns (Shower Head)
: 1
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: 200
⤷ Rail Length
: 1110

Additional Info & Downloads

Download the Customer Data Sheet Pdf File

Total: £506.99 3-4 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Sequential Control In Showers

Sequential Control lets you turn the shower on and off and regulate the temperature by turning the same knob. The built-in integral check valves and strainers make it easy to use. The first movement of the knob turns the shower to the cold position, and any subsequent anti-clockwise movement increases the temperature to a set maximum.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Chris Asked :
Is this shower suitable for high pressure, i.e. pumped?

Answered By QS Team

The shower valves are suitable for use with all water supply systems up to a maximum of 5.0 Bar. Operating pressures above 5.0 Bar will require the installation of pressure-reducing valves. Maximum Static Bar - 10 bar, Hot Supply - 55-65°C, Cold Supply - Maximum 25°C and Mixed water - Maximum 44°C.
