Nuie Steel Curved Heated Towel Rail with Brackets

Nuie Bathroom Details

MFC: MTY102

Brand Nuie innovations come with superior technical detailing fused with meticulous styling. This fact is well exemplified by Nuie Curved Ladder Towel Rail. The attractive, ladder-like profile is updated with an Anthracite and Chrome and can be purchased in 3 height choices. This svelte piece has a finish that contributes to its contemporary, tubular structure and excellent appeal.

Supplied with fixing screws, it is easy to install and has an impressive heating capacity. So, make your bathroom stylishly comfortable and warm at an attractive price and rest assured with a five-year guarantee. This towel rail brings style and warmth to your bathroom space.

Key Features

✔Manufactured using Steel Material
✔It comes Complete with Brackets and Fixing Screws
✔CE-Certified Product
✔5-Year Guarantee from Nuie against Manufacturing Defects

Choice of Finishes: Anthracite and Chrome - [Optional]
Choice of Heights: 700mm, 1100mm and 1150mm - [Optional]
Width: 500mm (50cm)
Luxury Heated Ladder Rail
Suitable for Use with Heating Elements
All Tappings are 1/2-Inch BSP
The Image Shown is for Illustration Purposes Only
Electric Element - [Optional]
Radiator Hook - [Optional]
Suitable Valve available in Compatible Valves Tab Below - [Optional]
For Details on the Towel Rail, Refer to the Chart at the Product Variations Info & MFC Code Tab Below
Download Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section
After Installing, when Refilling the System, it is Recommended that a Suitable Inhibitor is used
We Recommend Pipework is Not Installed until Receipt of the Radiator or Heated Towel Rail
Valves and Elements are Not Included

Note: It is recommended that pipework is not installed until the receipt of heated towel rail. Dimensions are subject to minor deviations and image shown is just for illustration purpose.
Warning and Precautions: The qualified persons should make all electrical and plumbing connections. When fitting with heating elements, the radiator or rail must always be mounted with the element at the bottom with the radiator or rail in the upright position. If fails to do so, it may result in a fire hazard.

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ No. of Tubes
: 14
⤷ Colour
: Anthracite
⤷ Shape
: Curved
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Width
: 500
⤷ Height
: 700
⤷ Fixings included
: Yes
⤷ Orientation
: Vertical

⤷ Barcode
: 5055369044115
⤷ BTU Output
: 30°C - 560 | 50°C 1051| 60°C - 1331
⤷ Watts
: 30°C - 164 | 50°C - 308 | 60°C - 386
⤷ Tapping / Pipe Centres
: 450
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating | Electric
⤷ Floor to Centre of Inlet
: 65
⤷ Tube Diameter
: 22
⤷ Heating Element Included
: Sold Separately
⤷ Element Type
: Standard
⤷ Brackets Included
: Yes

Additional Info & Downloads

Download the Customer Data Sheet For 500 x 700mm Pdf File Download the Customer Data Sheet For 500 x 1150mm Pdf File Download the Customer Data Sheet For 500 x 1100mm Pdf File Download the Installation Instruction Pdf File

Technical Images

Nuie Steel Curved Heated Towel Rail with Brackets - 500mm Wide

£41.44

RRP: ~~£119.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

Product Variations Info & MFC Code

Height	Projection	Finish	BTU At 30 Deg.C	BTU At 50 Deg.C	BTU At 60 Deg.C	Watts At 30 Deg.C	Watts At 50 Deg.C	Watts At 60 Deg.C	Pipe Centres	Number Of Tube	Heat Settings	Packaging Volume (L)
700mm	100mm	Anthracite	560	1051	1331	164	308	386	450mm	13	1	23
1150mm	70mm	Anthracite	894	1689	2139	262	495	622	450mm	21	1	37
-	-	-	-	-	-	-	-	-	-	-	-	-
700mm	90mm	Chrome	710	366	899	208	107	258	450mm	14	1	-
1100mm	-	Chrome	1126	581	1426	330	170	410	450mm	-	-	-

2 Features Included In This Product Explained

RAL Colours

It refers to a European colour-matching system which defines colours for coatings, paints, and plastics. The colour standard is administrated by the RAL Deutsches Institut für Gütesicherung und Kennzeichnung.
Read more...

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.
