Geberit AquaClean Sela 375 x 565mm Wall Hung WC Pan And Seat

Geberit AquaClean 146.220.11.1 Details

The Geberit AquaClean Sela Wall Hung WC Pan and White Alpine Seat that boasts a fashionable appearance and features a seat that is available in two stylish finish options. Complete with a spray intensity that can be set to one of 5 different levels and a spray arm that can be placed in 5 different positions, this product also includes a descaling program to assure that keeping it clean is as easy as possible as well. A rimless, high-quality appliance with TurboFlush technology included, this product also boasts up to 4 programmable user-profiles and includes user detection.

Toilet seat available in different finishes: White Alpine and Gloss Chrome - Plated - [Optional].
Complete solution wall-hung WC pan and seat.
Overall size [mm]: 375mm x 390mm [Width x Height].
Overall size [cm]: 37.5cm x 39cm [Width x Height].
Projection from wall: 565mm (56.5cm).
Suitable for convenient toilet use and for gently cleaning sensitive areas with water.
Separate Lady shower nozzle in the protected park position.
Adjustable shower water temperature.
Spray intensity can be set to five different levels.
The spray arm can be placed in five different positions.
Adjustable oscillating spray (automatic forward and reverse motion of the spray arm).
Automatic pre and post-rinsing of the spray nozzle with fresh water.
Descaling programmed.
User detection.
WC seat ring and WC lid with soft-closing mechanism.
WC lid with SoftOpening.
Activation of the orientation light via a brightness sensor.
Orientation light can be set in seven colours.
Functions and settings via remote control.
Four user profiles can be programmed.
Compatible with the Geberit AquaClean app.
Water supply connection on the left, hidden behind the WC ceramic.
Mains connection with flexible three-wire sheathed cable, on the right side, hidden behind the WC ceramic.
External water supply connection on the left possible with accessories.
External mains connection with a power outlet on the right possible.
Approval under (DIN) EN 1717 / (DIN) EN 13077.

Protection class: I.
Protection degree: IPX4.
Nominal voltage: 230 V AC.
Mains frequency: 50 Hz.
Power consumption: 1850 W.
Power consumption standby / with the heating switched on = 0.5 W.
Flow pressure: 0.5-10bar.
Operating temperature: 5-40 °C.
Water temperature, adjustment range: 34-40 °C.
Calculated flow rate: 0.02 l/s.
Minimum flow pressure for calculated flow rate: 0.5 bar.
Spray time: 50 s.
Maximum load WC seat: 150 kg.
Control panel for AquaClean Sela WC [Optional].
Refer to the technical drawing for more technical specifications.
Download Installation Manual and Quick Guide PDF File from the Additional Info Section.
Scope of delivery:.
Water supply connection set for Geberit Sigma concealed cistern 12 cm, and Geberit Omega concealed cistern 12 cm, installation height 112 cm.
Female socket for mains connection.
Sound insulation set.
Spray shield.
Cleaning set.
Descaling agent, 125 millilitre.
Connection set for WC, Ø 90 mm.
Remote control with wall-mounted case and battery CR2032.
Fastening material.

Info / Size (mm)

Toilet
Width: 375 mm
Projection: 565 mm
Height: 390 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: AquaClean
⤷ Toilet Design
: Wall Mounted
⤷ Coating
: Without Coating
⤷ Colour
: White
⤷ Country of Origin
: Germany
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Installation Type
: Wall-Hung
⤷ Projection (Depth)
: 565
⤷ Width
: 375

⤷ Outlet
: Horizontal
⤷ Configuration
: WC Pan And Toilet Seat
⤷ Height
: 390
⤷ Seat Included
: Yes
⤷ Seat Type
: Soft-Close
⤷ Fixings included
: Yes
⤷ Compliance/Approvals/Standard
: (DIN) EN 1717 / (DIN) EN 13077
⤷ Barcode
: 4025416284857
⤷ Bowl Shape
: Round
⤷ Product Type
: Wall Mounted Toilet

Additional Info & Downloads

Download the User Manual Pdf File Download the Installation Manual Pdf File Download the Quick Guide Pdf File

Customise Your Product

Optional Accessories

The AquaClean Sela control panel from Geberit is suitable for exposed installation and manual, wireless operation of the shower toilet. Please Note: The image shown is for illustration purposes only.

None
OP-162082 - Wall-Mounted Control Panel For WC - 147.041.SI.1 + £629.70

Total: £4590.00 5-7 Working Days Approx QS Supplies

9 Features Included In This Product Explained

Rimless

A rimless toilet does not have a brim at its edge, from which the water usually flows when you flush. Instead of flowing from the top, such toilets shoot water towards its edge and around it, allowing no missing spots with filth remaining after a flush. These toilets also remove any spaces for germs to hide and breed, providing a hygienic alternative for your bathroom.

Orientation Light

It is a motion-sensitive LED light included with the Geberit system. It is built into the unit, so it turns on automatically when you approach it. This gentle beam is bright enough to help you find your way and makes your night-time bathroom trip a pleasant experience. You can further customise the settings, making the lights bright or dim based on your preference.

Special Glazed Keratect

KeraTect glaze is a hygienic, smooth, and non-porous surface treatment that's easy to clean, scratchproof, and durable. In addition, it protects the unit from dirt build-up and ensures it looks great for years to come.

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Mains-Operated

Mains-operated devices work on electricity by plugging into electrical wall sockets. These require higher electrical energy and can't be operated using batteries as small batteries can't power the device. Large, non-portable electrical appliances are typically mains operated.

Intuitive Remote Control

The Geberit shower toilets can be operated simply and intuitively using the remote control. Easy to use, users can select their respective profiles from the stored user's settings and can then access their preferred spray arm position, oscillating spray or spray intensity setting. It can be screwed or fastened to the wall without cables. Alternatively, these functionalities can also be accessed with the manufacturer's Home App, specially made for these toilets.

Whirlspray Technology

The WhirlSpray technology integrated with Geberit shower toilets ensures gentle, thorough cleaning using a double water jet. The pulsating spray offers outstanding comfort, incorporating air and hot water at a constant temperature with a continuous flow heater.

Turbo Flush

The TurboFlush technology is a particular ultra-quiet feature of the Geberit toilet design. After flushing the toilet, water flows laterally into the unit and through the interior in a spiral way, and the flow is guided for optimal hygiene.

Washdown Model

A washdown toilet uses the weight of the water and gravity to push out the toilet waste from the toilet bowl. The washdown toilet is designed with a short and wide trapway, so that waste can quickly enter the trapway using just the force of water from the tank. A washdown model includes a push-button flush and has a skirted design with a smaller water surface area and a short trapway and can easily handle heavy loads without getting clogged.
