Hudson Reed Revolution Industrial Twin Shower Valve

£175.56

STOCK AVAILABILITY

5 Working Days Approx

Not Yet Rated No Rating

Shipping: £7.95

Product Variants
Select Finish Step 1
Select Variation Step 2
SKU Code: QS-V93791

MFC Code: SIWTW01

Hudson Reed Revolution SIWTW01 Details

Hudson Reed Revolution Industrial Twin Shower Valve comes in two variants with or without diverter. It displays an Industrial design that has been given a stunning chrome finish. It has a Width of 100mm, Depth of 143mm and a height of 220mm and is suitable for low-pressure water systems. It requires a minimum of 0.1 bar of water pressure to operate smoothly and can be ideal for industrial applications. The WRAS, TMV2 and TMV3approved valve is suitable for use with all systems and backed by a 20-year guarantee from the manufacturer against manufacturing defects.

Key Features
  • Choice of different finish: Chrome, Matt Black and Brushed Brass [Optional]
  • Quarter turn valve operated
  • High-quality internal brassware
  • Guarantee: Twenty years from Hudson Reed against manufacturing defects
  • Available in different variants: Without Diverter Or With Diverter [Optional].
  • Size: Width 80mm x Depth 143mm x Height 215mm.
  • Compatible to use for industrial purposes.
  • Accurate flow control.
  • Excellent flow rates.
  • Suitable for use with all systems: gravity-fed pumped unvented high pressure or fully modulated combi-boilers.
  • For complete size details, please refer to technical drawing.
  • During installation, extra care must be taken to avoid damaging the fittings.
  • Details For Without Diverter:.
  • Pipe size: 15mm (1/2inch BSP).
  • No. of outlets: 1.
  • Approval: WRAS, TMV2 and TMV3.
  • Suitable for low-pressure water system.
  • Requires a minimum of 0.1 bar or above water pressure to operate smoothly.
  • Details For With Diverter:.
  • Pipe size: 15mm and 22mm.
  • No. of outlets: 2.
  • Suitable for medium-pressure water system.
  • Requires a minimum of 0.5 bar or above water pressure to operate smoothly.
  • Download Customer DataSheet PDF from the Additional Info Section.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Chrome
  • ⤷ Warranty/Guarantee
  • : 20 Year
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Inlet Connections
  • : G.1/2
  • ⤷ Minimum Operating Pressure (Bar)
  • : 0.1
  • ⤷ Flow Rates (l/min)
  • : 0.1 bar - 5.5, 0.5 bar - 14, 1 bar - 20, 2 bar - 29, 3 bar - 44
  • ⤷ WRAS Approved
  • : Yes
  • ⤷ Backplate Width
  • : 100
  • ⤷ Backplate Height
  • : 220
  • ⤷ TMV2 Approved
  • : Yes
  • ⤷ TMV3 Approved
  • : Yes
  • ⤷ Number of Handles
  • : 2
  • ⤷ Plumbing System Compatibility
  • : Suitable for use with all systems
  • ⤷ Plumbing Option
  • : Concealed
  • ⤷ Cartridge Included
  • : Yes
  • ⤷ Cartridge Type
  • : Quarter Turn

Additional Info & Downloads

Download PDF Download the Customer Data Sheet For With Or Without Diverter Pdf File


Technical Images


Total: £175.56 5 Working Days Approx QS Supplies

7 Features Included In This Product Explained

Combi-Boiler System

Combi-Boiler System

The showerhead or shower system is suitable for use with a Combi-Boiler System. This system heats cold water on demand, relying solely on mains pressure to move water around your home. These are suitable for mixer showers, as they provide hot water instantaneously and at the highest pressure.

Unvented System

Unvented System

The unvented water systems usually have a separate hot water cylinder, which is pre-heated via a combi boiler or other heating sources to store a quantity of hot water at mains pressure.

Optional: Diverter In Showers

Optional: Diverter In Showers

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

TMV2 Approved Product

TMV2 Approved Product

TMV2 is an independent certification for thermostatic mixers, including shower valves, run by BuildCert that ensures national and international standards as specified under (BS EN 1111 and 1287) are met. These standards detail the exacting requirements that a thermostatic valve or product must comply with to guarantee a high thermostatic protection and safety standard. Products meeting this requirement carries the logo and protect against any scalding accidents.

TMV3 Approved Product

TMV3 Approved Product

TMV3 approval means a thermostatic valve is certified and approved for use in healthcare and commercial situations.

WRAS Approved Product

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

Low Water Pressure

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
