Bristan Design Utility Chrome Bar Shower Mixer With Adjustable Riser Kit

Bristan Design DUL2 SHXARFF C Details

The Bristan Design Utility Bar Shower Mixer with Adjustable Riser Kit combines smooth curves and the latest thermostatic technology to create a highly functional and attractive shower space. The cylindrical mixer is equipped with dual controls for flow and temperature, giving smooth and accurate control over both. Also, the valve features a pre-set maximum temperature of 38 degrees, which can be boosted to 46 degrees by using the push-button override.

It is built using premium quality brass which will keep it strong and robust for many years to come. A lengthy shower hose and a paddle-shaped rub-clean handset allow for a thorough and invigorating soak, and the height-adjustable bracket on the riser rail bears the same cylindrical style as the bar mixer.

Manufacturing code of this product: DUL2 SHXARFF C.
Supplied with 1500mm (150cm) hose, riser rail, hose retainer and single-function handset.
Features WRAS and TMV2 approved.
It comes in a fabulous chrome finish.
Contemporary and stylish design.
Nominally equal (balanced) inlet supply pressures are required for optimum performance.
Inlet connection 15mm compression.
Features dual control - Flow and temperature are controlled separately, giving accurate control.
Flow rate at 0.2 bar open outlet (without hose & flow regulators): 5.7 l/min.
Temperature: Pre-set 38ºC. With push-button override to 46ºC.
Fast-fit connectors for easy retro-fit installation.
Easy-to-use lever handles.

The shower kit has an adjustable fitting bracket on the riser rail to enable existing screw holes to be used.
A wide bore hose maximises flow through the handset.
Rub clean handset.
Chrome plated to BS EN 248.
Width of the valve: 300mm - (30cm).
Inlet centre of the valve: 150mm - (15cm).
Height of Rail: 650mm - (65cm).
Suitable for low and high water pressure systems.
Requires a minimum of 0.2 bar to a maximum of 5.0 bar of water pressure.
Download the Installation Instruction PDF File From The Additional Info Section.
For complete size details, please refer to technical drawing.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Valve/Cartridge Type
: Exposed
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes

⤷ Hose Length
: 1500
⤷ Temperature Control
: Thermostatic
⤷ Compliance/Approvals/Standard
: TMV2, WRAS
⤷ Riser Rail & Kit Finish
: Chrome
⤷ Valve Size
: W-300, H-70, D-165
⤷ Rail Length
: 650

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £170.66 2 Working Days Approx QS Supplies

7 Features Included In This Product Explained

Family Safe

This feature corresponds with the Thermostatic mechanism and automatic safety stops, preventing running water from getting either too hot or too cold.

Luminance Chrome

It is a hard-wearing chrome plating which is salt-tested and scratch-proof for durable, long-lasting use.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.

Drenching

Drenching in Bristan showers means these showers soak you thoroughly, giving you the most indulgent showering experience.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...
