Vado Celsius Chrome Thermostatic Shower Valve with Evolve Slide Rail Kit and Wall Outlet

Vado Celsius Details

MFC: DX-17120-CELRO-CP

Vado Celsius Chrome Thermostatic Shower Valve with Evolve Slide Rail Kit and Wall Outlet.

Manufacture Code of this Product: DX-17120-CELRO-CP
Wall-Mounted Installation
Suitable for Low and High Water Pressure Systems
Works on a Minimum 0.2 bar to a Maximum 5.0 bar Water Pressure
Pack Includes:
1 Outlet Thermostatic Shower Valve - CEL-148D/RO-C/P
Evolve 4 Function Slide Rail Shower Kit - EVO-MFSRK-DB-C/P
Elements Wall Outlet - ELE-OUTLET2-CP
Features of 1 Outlet Shower Valve:
Diameter of Backplate: Ø196mm
Incorporates with Circular Backplate
Thermostatic Cartridge V-704-34S, Flow Cartridge C-301-RTC
2 x 3/4 Inch Female Inlets, 1 x 3/4 Inch Female Outlet
Includes 3/4 Inch - 1/2 Inch Adaptors
Minimum-Maximum Wall Mount: 70-95mm
Optimum Installation Depth: 82mm
Includes Bleed Valve for System Flush on Installation
Features of the Slide Rail Kit:
4-Function Handset
Rub Clean Nozzles
Size of Handset: 110 x 255mm [Width x Height]
Height of Slide Rail: 680mm
Length of Shower Hose: 1500mm
Features Of Wall Outlet:
Diameter: Ø55mm
Threaded Inlet: 1/2 Inch
Threaded Outlet: 1/2 Inch
Refer to the Technical Diagram for Complete Technical Dimensions
Download the Installation Instruction and Product Data Sheet PDF File from the Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes
⤷ Hose Length
: 1500
⤷ Temperature Control
: Thermostatic

⤷ Backplate Width
: 196
⤷ Backplate Height
: 196
⤷ Product Type
: Shower Set
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: 4
⤷ Rail Length
: 680
⤷ Outlet Elbow Included
: Yes

Additional Info & Downloads

Download the Product Datasheet Pdf File Download the Installation Instructions of Valve Pdf File

Vado Celsius Chrome Thermostatic Shower Valve with Evolve Slide Rail Kit and Wall Outlet

£423.50

RRP: ~~£770.00~~

Stock Availablity: 3-4 Working Days Approx

QS Supplies

4 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.
