Vado Individual Omika Noir Concealed Thermostatic Shower Valve With Geometric Accents

Vado Individual Omika Noir IND-T148/2-OMI-PB Details

Available in 2 variants: Vertical and Horizontal.
Available in outlet variant: 2 Handle with 2 outlets and 3 handle with 3 outlets.
Min-Max wall mount: 75-100mm (7.5-10cm).
Optimum installation depth: 87mm (8.7cm).
2 x 3/4" female inlets.
2 x 3/4" female outlets includes 3/4" - 1/2" adaptors.
Thermostatic cartridge [V-704-34S] diverter cartridge [FL-802-33/2MX].

Minimum water pressure required for shower 0.2 bar [Low Pressure].
Minimum water pressure required for bath 1.0 bar [High Pressure].
Includes mortar tile guard.
Compatible with Studfast [Optional].
Refer to the technical drawing for complete size details.
Download the User Guide and Installation Instruction PDF File from the Additional Info Section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Omika Noir
⤷ Colour
: Polished Black
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ No. of Holes Required
: 2
⤷ Min-Max Wall Mount
: 75-100
⤷ Minimum Operating Pressure (Bar)
: 0.2 - Shower / 1.0 - Bath

⤷ Handle Style
: Knob
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 80
⤷ Backplate Height
: 170
⤷ Number of Handles
: 2
⤷ Number of Outlet
: 2
⤷ Orientation
: Portrait
⤷ Product Type
: Shower Valve
⤷ Plumbing System Compatibility
: Gravity System, Pumped System, Combination Boiler, Pressurised System

Additional Info & Downloads

Download the User Guide For 2 Way Vertical Thermostatic Shower Valve Pdf File Download the User Guide For 2 Way Horizontal Thermostatic Shower Valve Pdf File Download the User Guide For 3 Way Horizontal Thermostatic Shower Valve Pdf File Download the Installation Instruction For 2 Way Vertical Thermostatic Shower Valve Pdf File Download the Installation Instruction For 2 Way Horizontal Thermostatic Shower Valve Pdf File Download the Installation Instruction For 3 Way Horizontal Thermostatic Shower Valve Pdf File

Total: £731.26 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

All Flow

The All flow function within the shower valves enables the water to flow to either individual shower outlets or all outlets simultaneously.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
