Hudson Reed Topaz Twin Exposed Thermostatic Shower Valve Chrome-White-TSVT101

Hudson Reed Topaz TSVT101 Details

Hudson Reed Topaz Thermostatic Shower Valve makes a strong statement with its smart, industrial look. The exposed shower valve incorporates a patented cartridge which is highly resistant to calcium build-up, especially in hard water areas. Suitable for use with all systems, gravity-fed pumped, unvented high pressure or fully modulated combi-boilers. To ensure a safe and comfortable showering experience, this valve includes a thermostatic cut-off mechanism to prevent scalding in the event of the cold water feed failing. Made from superior grade brass, this will offer long-term performance adding immense value. The stunning chrome finish adds a touch of luxury and sophistication to the shower space.

Exposed wall-mounted installation.
Size [mm]: 195mm x 135mm x 206mm [Width x Depth x Height].
Size [cm]: 19.5cm x 13.5cm x 20.6cm [Width x Depth x Height].
Inlet Centers: 149mm (14.9cm).
Manufactured using solid brass material.
Quarter-turn ceramic disc.
Stain rust resistant.
Suitable for low water pressure system.
The minimum water pressure recommended for smooth working is 0.1 bar [LP-Low Pressure].
The minimum flow rate is 5.5 litres per minute at 0.1 bar water pressure.
Features and Specification:.

Accurate flow control and excellent flow rates - even at low pressure.
Thermostatic control to +/- 1 °C even if the water pressure fluctuates.
Anti-Scald - Full thermal protection to prevent scalding in the event of hot or cold water shut off.
In the event of hot or cold water failure, the valve will shut down automatically.
The patented cartridge is highly resistant to calcium buildup - even in hard water areas.
Suitable for use with all systems, gravity-fed pumped unvented high-pressure or fully modulated combi-boilers.
The cartridge is fully reversible, meaning if hot and cold supplies are the wrong way round, it doesn't need re-plumbing - simply remove the cartridge, turn 180° and replace.
Refer to the technical drawing for complete size details.
Download Customer Datasheet And Installation Instruction PDF File from the Additional Info Section.
Twenty-year guarantee from Hudson Reed against manufacturing defects.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome And White
⤷ Warranty/Guarantee
: 20 Years
⤷ Material
: Solid Brass
⤷ Theme
: Traditional
⤷ Installation Type
: Wall Mounted
⤷ Inlet Centres
: 149
⤷ Overall Height
: 206
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Flow Rates (l/min)
: 0.1 bar - 4.5 , 0.5 bar - 13 , 1 bar - 18.5 , 2 bar - 26 , 3 bar - 33
⤷ Handle Style
: Crosshead Lever

⤷ Depth
: 135
⤷ Temperature Control
: Thermostatic
⤷ Anti-Scald
: Yes
⤷ Number of Handles
: 2
⤷ Plumbing System Compatibility
: All
⤷ Plumbing Option
: Exposed
⤷ Overall Width
: 195
⤷ Cartridge Included
: Yes
⤷ Cartridge Type
: 1/4 Turn Ceramic Disc

Additional Info & Downloads

Download the Customer Datasheet Pdf File Download the Installation Instruction Pdf File

Customise Your Product

Shower Elbow

It is made from brass back-to-wall shower elbow for hidden pipework from Hudson Reed. Please Note: The images shown are for illustration purposes only.

None
OP-153990 - Back-To - Wall Shower Elbow + £13.26

Total: £180.50 2 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Combi-Boiler System

The showerhead or shower system is suitable for use with a Combi-Boiler System. This system heats cold water on demand, relying solely on mains pressure to move water around your home. These are suitable for mixer showers, as they provide hot water instantaneously and at the highest pressure.

Unvented System

The unvented water systems usually have a separate hot water cylinder, which is pre-heated via a combi boiler or other heating sources to store a quantity of hot water at mains pressure.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

jo Asked :
Hi, Does this come with all the accessories to connect to the plumbing? I have two half/12mm inch pipes (eire copper) exposed at 150mm centres. Does this have a mounting kit or need one that is purchased separately? Finally, what is the cost of carriage to the Rep of Ireland? Regards, Jo

Answered By QS Team

Yes, this will come with the necessary parts to connect it to your pipework. For Shipping cost for Ireland, you need to contact our sales department at 0116 251 0051.
