Geberit Monolith Sanitary Module with Cistern for Wall Hung WC - 480 x 1010mm

The Geberit Monolith Sanitary Module for Wall Hung WC is a dual flush, self-supporting unit. It speaks a new language of form in bathroom design, as you can combine it with numerous ceramic fittings in a new or renovated bathroom. No structural changes need to be made, and no walls need to be opened before installation, making it fast, easy and hassle-free.

It is included with Cistern, fully insulated against condensation, and is ideal for renovations, conversions, and new buildings. Go high on luxury and comfort with this WC frame with a design which lends it a sleek look. This is one product you will only have to try a little to help you make up your mind.

• The Manufacturing Code of this Product is 131.185.00.5
• Size of Frame in mm: 480 x 97 x 1010mm [Width x Depth x Height]
• Size of Frame in cm: 48 x 9.7 x 101cm [Width x Depth x Height]
• Monolith Sanitary Frame with a Dual Flush Concealed Cistern
• Adjustable Flush Volume: 6-3 Litres
• Cistern, Fully Insulated Against Condensation
• Fastening Height WC Ceramic Appliance 35 ± 1cm
• Height-Adjustable Up to 7cm
• Self-Supporting Sanitary Module
• Water Supply Connection at the Bottom
• Water Supply Connection on the Left/Right is Possible with Accessories
• Flush Actuation with Dual Action Levers - Sold Separately
• Cistern Lid with Flush Action-Levers and Side Claddings [Optional]
• Factory Setting Flush Volume: 6/3 Litres
• Flow Pressure: 0.1-10 Bar
• Large Flush Volume, Adjustment Range: 4.5/6 Litres
• Maximum Water Temperature: 25° Celsius
• Small Flush Volume: 3 Litres
• Compensation of Dimensional Tolerances is Possible
• Refer to the Technical Drawing for More Size Details
• Download the Installation Instructions and Technical Data Sheet Customer-Specific Front Cladding PDF from the Additional Info & Download Section
• Application Purposes:
• For Compensating the Offset Between WC Connections and Wall Drains Using a Stepped Straight Connector for Wall-Hung WCs
• For Connecting Geberit AquaClean WC Enhancement Solutions with Accessories
• For Geberit AquaClean WC Complete Solutions
• For Installation in Front of Drywalls or Solid Walls
• For Mounting on Finished Floors
• For Renovations, Conversions and New Buildings
• For Replacing Low-Level Exposed Cisterns
• For Replacing Wall-Hung WCs with Close-Coupled Exposed Cistern
• For Wall inlets with Inlet Height > 23cm
• Scope of Delivery:
• 2x Threaded Rods M12
• 6x Fastening pins
• Adapter Socket Made of PE-HD, Ø 90/110mm
• Base Cover
• Fastening Material
• Fastening Material for Drywall
• Flush Bend Extension 160mm
• Sleeve Made of EPDM, Ø 44/55mm
• Straight Connector Made of PE-HD, Ø 90mm
• Support Frame
• Water Supply Connection Set with 2x Angle Stop Valves, 1/2-Inch
