RAK Sensation Wall Hung White Rimless WC Pan With Urea Soft Close Seat


RRP: £523.00


In-Stock In Stock

3.8 out of 5 3.8 out of 5

Based on 89 Ratings.

Shipping: FREE* Check Postcodes

Delivery in 2 Working Days Approx.
Select Variations
You've Selected: OP-185755 - Mini - 485mm Projection
Key Features
  • Includes: Pan and Urea Soft close seat
  • It comes in an Alpine White finish
  • Made from the best quality vitreous china material
  • Rimless bowl
  • Hidden fixations with no lateral holes
  • Twenty-five years of guarantee from the manufacturer
SKU Code: QS-V103031


RAK Sensation SENWC1447AWHA Details

RAK Sensation Mini Wall Hung Rimless WC Pan With Urea Soft Close Seat is available in Mini and Maxi sizes. The Wall Mounted WC pan has hidden fixations with no lateral holes for a clean finish. Made from the best quality vitreous china material, it has a rimless Bowl that ensures high hygiene and easy cleaning. The white profile gives it a high-end and sophisticated look, while a matching soft-close seat ensures quiet and comfortable operation. Suitable to use with WC frame.

  • Available in 2 sizes: Mini & Maxi.
  • Installation Type: Wall Mounted.
  • Mini toilet - Projection from wall: 485mm - (48.5cm).
  • Maxi toilet - Projection from wall: 520mm - (52cm).
  • Width: 380mm - (38cm).
  • Height: 350mm - (35cm).
  • Bowl shape: Oval.
  • Weight: 23.5 Kg.
  • Refer to the technical diagram for more technical details.
  • Toilet seats carry 2 year of guarantee from the manufacturer.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Toilet Design
  • : Back to Wall Toilet
  • ⤷ Range
  • : Sensation
  • ⤷ Coating
  • : Without Coating
  • ⤷ Colour
  • : Alpine White
  • ⤷ Weight in kg
  • : 23.5
  • ⤷ Country of Origin
  • : Dubai
  • ⤷ Warranty/Guarantee
  • : 25 Years
  • ⤷ Material
  • : Vitreous China
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Water Saving
  • : Yes
  • ⤷ Pan Width
  • : 380
  • ⤷ Pan Height
  • : 350
  • ⤷ Projection (Depth)
  • : 485
  • ⤷ Rimless Bowl
  • : Yes
  • ⤷ Outlet
  • : Horizontal
  • ⤷ Configuration
  • : WC Pan Only
  • ⤷ Configuration
  • : Pan Only
  • ⤷ Compact Design
  • : Yes
  • ⤷ Seat Included
  • : Yes
  • ⤷ Seat Type
  • : Soft Close
  • ⤷ Seat Finish
  • : White
  • ⤷ Fixings included
  • : Yes
  • ⤷ Fixing Holes Centre
  • : 180
  • ⤷ Barcode
  • : 5057199941459
  • ⤷ Distance from floor to centre of fixing hole
  • : 350
  • ⤷ Bowl Shape
  • : D-Shape
  • ⤷ Product Type
  • : Wall Hung Toilet
  • ⤷ Seat Post Hole Centers
  • : 155
  • ⤷ Front Of Bowl To Centre Of Seat Holes
  • : 430
  • ⤷ Pan fixing centres
  • : 180
  • ⤷ Outlet Diameter
  • : 100

Total: £262.69 3-4 Working Days Approx QS Supplies

5 Features Included In This Product Explained



A rimless toilet does not have a brim at its edge, from which the water usually flows when you flush. Instead of flowing from the top, such toilets shoot water towards its edge and around it, allowing no missing spots with filth remaining after a flush. These toilets also remove any spaces for germs to hide and breed, providing a hygienic alternative for your bathroom.

Soft-Close Seat

Soft-Close Seat

Soft-closing seats are a new alternative to classic toilet seats. Their modern design allows them to close slowly, while their controlled manner of closing does not require you to assist them. It also shuts automatically, allowing it to come down at a pace that does not make much noise.



It is a plastic moulded under high pressure and offers durability and rigidity with scratch and chemical resistance. It is also antimicrobial and anti-bacterial.

Hidden Fixation System

Hidden Fixation System

It is safe and easy and allows for greater design freedom. Easy and quick installation is made for products like Water Closets and Bidets with neatly concealed out-of-sight fixings. A single person can complete the installation without trouble using the fixation system, which holds up the ceramic for installation.

Vitreous-China Material

Vitreous-China Material

Vitreous china is an innovative glass-based enamel coating applied to porcelain. This glazed coating makes the base material durable, denser, and very glossy. When ceramics are coated with vitreous enamel, the resulting product is called vitreous china. This enamel is created by applying heat to powdered glass.

Product Videos

Video of RAK Ceramics hidden fixation systems

Product Variations Info & MFC Code
  • Available Sizes :
  • Mini - 485mm Projection - SENWC1447AWHA|RAKSEAT019
  • Maxi - 520mm Projection - SENWC1446AWHA|RAKSEAT019
Add-on Selected: Total Price Now:

Reviews & Ratings

Rate this Item.:

Questions & Answers

Submit Your Questions 5 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

AK Asked :

Does the toilet seat have easy release? What is the difference between White and Alpin White?

Answered By QS Team Answered by the QS Technical Team

Yes, they are quick-release. Alpine white is the colour of our pans, but there will only be the slightest difference in colour between the pan and seat because they are made of different materials.

Was this answer helpful?
Clair Asked :

Hi, Are the items below compatible? RAK Sensation Wall Hung White Rimless WC Pan With Urea Soft Close Seat, 485mm Projection QS-V103031 and Grohe Rapid SL 3 In 1 Set For WC With Flushing Cistern QS-V28644?

Answered By QS Team Answered by the QS Technical Team

We would recommend using RAK frames such as FS04RAK8C and FS04RAK12C for use with RAK Sensation Wall Hung White Rimless WC Pan With Urea Soft Close Seat.

Was this answer helpful?
Norman Asked :

Is the hinge for the RAK Sensation Mini chrome?

Answered By QS Team Answered by the QS Technical Team

Yes, the hinge for the RAK Sensation is chrome.

Was this answer helpful?
Peter Asked :

Do you supply the frame and cistern on which to hang wall-mounted WCs, and how long does the sale last?

Debbie Asked :

Please tell me what the maximum flush volume setting is safe or recommended for the RAK Sensation rimless wall-hung toilet.

Answered By QS Team Answered by the QS Technical Team

RAK WCs are designed to work with 3/6 litre flush cisterns.

Was this answer helpful?
