Reina Todi Steel Designer Radiator

Reina Todi RND-TDI080010K Details

The Reina Todi Steel Designer Radiator is suitable for use in electric, central and dual fuel heating systems and includes all the brackets required for installation along with the product itself. Available in two different height and width options to choose from, this remarkably strong and striking stainless-steel crafted unit features a stylish, polished appearance and true functionality all in one unit. Supplied with an air vent as well as an air plug, this product does not include the valves shown in the accompanying image.

Key Features

✔Manufactured using steel material
✔Supplied with Air vent and End plug
✔Brackets for radiator included
✔Five years guarantee from Reina against manufacturing defects
✔Choice of finishes available: black and chrome [optional]

Available widths: 180mm, 260mm and 415mm - [Optional].
Available Height: 800mm and 1200mm - [Optional].
Variants available: Central heating, Dual Fuel and Electric - [Optional].
Heating element type: Standard, On/Off Touch, LST Mini Round Thermostatic, Mini Round, Touch Thermostatic, LST Weekly Thermostatic and Weekly Thermostatic - [Optional].
Wall to pipe centres: 65mm-80mm (6.5cm-8cm).
Distance from wall: 100mm-115mm (10cm-11.5cm).
EN 442 compliant product.

Valves, Sleeving kit and chrome pipe kit [Optional].
For the Dual Fuel and Electric model, Heating Elements are highly recommended in combination with T-Piece.
For Electric models, Optional Liquid Filling is required with the heating element.
For BTU and Watts, Please refer to the Product Variations Info and MFC Code section.
The valves shown in the image are not included.
Download the Heating Element PDF files from the Additional Info section.
Refer to the technical diagram for complete technical dimensions.

Please Note: The appropriate wattage of the element if selected will be decided by the manufacturer, once the order is placed.

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Todi
⤷ Colour
: Black
⤷ Country of Origin
: Turkey
⤷ Warranty/Guarantee
: 5 Year
⤷ Material
: Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Width
: 108

⤷ Height
: 800
⤷ Orientation
: Vertical
⤷ Barcode
: 5057199904515
⤷ BTU Output
: 70°C - 435
⤷ Watts
: 70°C - 128
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating | Electric | Dual Fuel
⤷ Wall to Centre of Inlet
: 65-80

Additional Info & Downloads

Download the Heating Element Manual Instructions Pdf File Download the Details Of Heating Elements Pdf File

Technical Images

Customise Your Product

Optional Accessories

Reina provides optional accessories that you may require for the installation. The manufacturer highly recommends these Accessories. Please Note: The image shown is for illustration purpose only.

No Option Selected
OP-113634 - 200mm Chrome Pipe Kit + £14.14

Total: £126.48 5 Working Days Approx QS Supplies

Product Variations Info & MFC Code

Width	108mm	260mm	415mm
Pipe Centres	78mm	230mm	385mm
Wall To Pipe Centre	65-80mm	65-80mm	65-80mm
Wall Distance	100-115mm	100-115mm	100-115mm
Tube Quantity	2	4	6
Watts - Delta-70	257	407	607
BTU - Delta-70	876	1389	2070
BTU - Delta-60	718	1139	1697
BTU - Delta-50	565	896	1335
BTU - Delta-45	492	780	1163
BTU - Delta-40	425	674	1005
BTU - Delta-35	356	565	841
BTU - Delta-30	289	458	683
BTU - Delta-25	113	179	266
MFC	RND-TDI080010K	RND-TDI080026K	RND-TDI080041K

Width	108mm	260mm	415mm
Pipe Centres	78mm	230mm	385mm
Wall To Pipe Centre	65-80mm	65-80mm	65-80mm
Wall Distance	100-115mm	100-115mm	100-115mm
Tube Quantity	2	4	6
Watts - Delta-70	164	263	394
BTU - Delta-70	560	898	1342
BTU - Delta-60	459	736	1100
BTU - Delta-50	361	579	866
BTU - Delta-45	315	504	754
BTU - Delta-40	272	436	651
BTU - Delta-35	228	365	546
BTU - Delta-30	185	296	443
BTU - Delta-25	72	115	172
MFC	RDN-TDI080010	RDN-TDI080026	RND-TDI080041

Width	108mm	260mm	415mm
Pipe Centres	78mm	230mm	385mm
Wall To Pipe Centre	65-80mm	65-80mm	65-80mm
Wall Distance	100-115mm	100-115mm	100-115mm
Tube Quantity	2	4	6
Watts - Delta-70	304	629	900
BTU - Delta-70	1035	2144	3069
BTU - Delta-60	848	1757	2516
BTU - Delta-50	668	1383	1980
BTU - Delta-45	581	1204	1724
BTU - Delta-40	502	1041	1490
BTU - Delta-35	421	872	1248
BTU - Delta-30	342	708	1013
BTU - Delta-25	133	276	394
MFC	RND-TDI120010K	RND-TDI120026K	RND-TDI120041K

Width	108mm	260mm	415mm
Pipe Centres	78mm	230mm	385mm
Wall To Pipe Centre	65-80mm	65-80mm	65-80mm
Wall Distance	100-115mm	100-115mm	100-115mm
Tube Quantity	2	4	6
Watts - Delta-70	194	403	581
BTU - Delta-70	660	1373	1981
BTU - Delta-60	541	1125	1624
BTU - Delta-50	426	886	1278
BTU - Delta-45	371	771	1113
BTU - Delta-40	320	667	962
BTU - Delta-35	268	558	805
BTU - Delta-30	218	453	654
BTU - Delta-25	85	176	255
MFC	RDN-TDI120010	RDN-TDI120026	RND-TDI120041

7 Features Included In This Product Explained

Central Heating

'Standard' radiators and towel warmers are connected to your central heating system, so hot water flows through them to heat them.
Read more...

Optional: Dual Fuel

These radiators or towel warmers can run on a conventional gas-powered central heating system or via your mains electrical supply. You can choose whether or not you want your radiator or towel warmer to come on independently of your central heating system, which is especially useful in summer. These radiators are compatible with heating and hot water, whether the system is open (direct) or closed (indirect).

BTU Output

It is the short form of a British thermal unit (BTU or Btu) and is defined as the amount of heat required to raise the temperature of one pound of water by one degree Fahrenheit. It is a standard unit against which radiator efficiency is measured.
Read more...

Watts Output

Unit of power to measure electric current.

Air Vent

An air vent or a radiator air valve or bleed valve, is a small part of the radiator. Its role is to release trapped air or gases from inside the radiator, keeping the appliance heating efficiently and evenly. An Air vent can be an automatic air vent or manually opened to release air and are made of metal or plastic.

Optional Sleeving Kit

A sleeving kit in a radiator heating system are components or materials used to sleeve or insulate the pipes or tubes that circulate hot water or steam from the central heating source to the radiators or heating units. The sleeving kit provides thermal insulation and prevents heat loss, adding to the heating systems efficiency.

Optional: Radiator Valve

Radiator valves help control how much hot water enters and leave it, and the flow of water controls how much heat the radiator generates. These are usually found at the radiator's bottom left, and right corners, where the water pipes enter and exit, or can also be present at the bottom near the centre.
