Bristan Blueberry Kitchen Sink Mixer Tap With EasyFit Base

Technical drawing QS-V79148 / BLB EFSNK C

Additional image of Bristan Blueberry Kitchen Sink Mixer Tap With EasyFit Base

Bristan Blueberry Kitchen Sink Mixer Tap With EasyFit Base

QS-V79148

MFC CODE: BLB EFSNK C

£56.22

RRP: ~~£109.00~~ You Save £52.78 on RRP

3.7 out of 5

3 out of 3 customers rated 73%

Review this Product

STOCK AVAILABILITY

3 Working Days Approx

Shipping: £5.95

Description

Technical

For elevating the design quotient of your kitchen, adorn it with this stylish Kitchen Sink Mixer Tap from the posh Blueberry range of Bristan. For delivering superb performance, this unit is manufactured to high standards from top quality brass. It is supplied with easy to use metal lever handle and flexible connecting pipes. The attractive chrome finish of this unit will elevate the design quotient of your bathroom décor. A 5 year manufacturer guarantee against any manufacturing defects supports this unit.

+ Read what's included.. & options available

Please Note all the measurements are in 'mm'

Colour	Chrome
Warranty/Guarantee	5 Years
Material	Brass
Theme	Modern
Installation Type	Deck Mouted
No. of Holes Required	1
Valve Included	Yes
Handle Material	Metal
Base To Spout	227
Spout Reach	161
Overall Height	292
Max. Deck Thickness	50
Inlet Connections	1/2 inch BSP
Minimum Operating Pressure (Bar)	0.5
Flow Rates (l/min)	9.8 (l/min) at 0.5 bar
Handle Style	Lever
WRAS Approved	Yes

Optional Feature

No Option Selected
OP-111601 - Tap Without EasyFit Base - BLB EFSNK C TO + £0.00

Bristan Blueberry BLB EFSNK C DETAILS

Tap
Pipe Centre: 161 mm

Manufacturing code of this product is BLB EFSNK C
Comes in chrome finish
Tap supplied with EasyFit base
Tap without EasyFit base - [Optional] - BLB EFSNK C TO
Manufactured using brass material
Deck mounted installation
Contemporary and stylish design
Maximum Hot Water Temperature : 65°C
Maximum Static Pressure : 10 bar
Ceramic disc 35mm cartridge for added durability and ease of use

Supplied with metal handle fixing nut
Height : 292mm
Center of inlet to center of outlet : 161mm
Base to spout : 227mm
Inlet connection : 1/2 inch BSP flexible tails
Suitable for low water pressure system
Requires minimum 0.3 bar or above 5.0 bar water pressure
Download installation instruction PDF
Refer technical diagram for complete technical dimensions
5 years guarantee against any manufacturing defects.

FEATURES INCLUDED IN THIS PRODUCT EXPLAINED

Step1 Fitting the Base
The first step is to slot the base of the tap into the sink. For this, detach the plain barrel from the EasyFit Base. Unscrew the fitting and push it through the hole in the sink or work surface. It must be in the central position which is indicated by the word ‘FRONT facing forward. Now tighten the fitting to the surface with a hex key. Lastly, the plain barrel must be replaced.
Step 2 Fitting the Tails
Next, you need to connect the integral flexible tails to the hot and cold water sources after you have closed the built-in valves.
Step 3 Fitting the Tap Body
Push and secure the tap body to the base using grub screws, which are present on either side of the tap body. The grub screws must be tightened using the hex key.

ADDITIONAL INFO

Download the Installation Instruction Pdf File

Total: £56.22 3 Working Days Approx QS Supplies

You've Selected which adds to a total of

You May Also Require

REVIEWS & RATINGS

Rate this Item.:

WRITE A REVIEW

Questions & Answers

Submit Your Questions 2 Questions Asked

Have a question about this item? Ask our tech team. We aim to reply within 72 hours. If you want to know get answers fast, please call us on 0116 251 0051

PETER Asked :

What size hole do you need in worktop for blueberry easyfit tap?

Answered By QS Team :
Thanks for your question, I can confirm the hole cutting size is 34 - 38mm

Was this answer helpful? Yes - No

Pat Asked :

The bristan blueberry tap keeps having water running out for at least 10 seconds and then drips, sometimes water just runs out then stops on its own? It is also very wobbly on the sink unit. What is wrong with this tap.

Answered By Malcolm :
We have no problem with it being wobbly but do find that occasionally when the tap is turned off, up to a minute later there will suddenly be some water spurt out.

Answered by Verified Purchaser Was this answer helpful? Yes - No
