Vado Celsius Thermostatic Chrome Shower Pack with Atmosphere Slide Rail Kit and Head

Vado Celsius Thermostatic Chrome Shower Pack with Atmosphere Slide Rail Kit and Head

• The manufacturing code of this product is DX-172252-CELSQ-CP
• Specification of Celsius Shower Valve - CEL-148D/2/SQ-C/P
• Includes Bleed Valve for System Flush on Installation
• Wall-Mounted Installation
• With the Rectangular Backplate
• Size [mm]: 130 x 200mm [Width x Height]
• Includes 3/4-Inch - 1/2-Inch Adaptors
• Minimum-Maximum Wall Mount: 70-95mm (7cm - 9.5cm)
• Optimum Installation Depth: 82mm (8.2cm)
• With Integrated Diverter
• 2 x 3/4-Inch Female Inlets
• 2 x 3/4-Inch Female Outlet
• Diverter Cartridge: FL-804-33X/3X
• Minimum Operating Pressure: 0.2 Bar - Low Pressure [Shower], 1.0 Bar - High Pressure [Bath]
• Studfast Concealed Shower Valve Mounting Brackets [Optional]
• Specification of Saturn Shower Head - ATM-HEADRO/B/SA-C/P
• Single-Function Fixed Showerhead
• Features Air Injection Technology - Infuses the Air with Water Particles Together
• It also Provides the Added Benefit of Reducing Water Consumption by up to 50%
• Suitable for High Water Pressure System
• Supplied Complete with Shower Arm
• Requires Minimum 1.0 Bar Operating Pressure
• Length of Arm: 390mm
• Diameter of Round Head: Ø200mm
• Size of Square Head: 200mm x 200mm
• Wall-Mounted
• Specification of Venus Shower Kit - ATM-MFSRKWO-CP
• Slide Rail Shower Kit
• Atmosphere Air-injected Multi-Function Slide Rail Shower Kit with Hose
• Rub-Clean Nozzles
• Integrated Outlet
• Height of Slide Rail: 900mm (90cm)
• Length of Shower Hose: 1500mm (150cm)
• Requires Minimum 1.0 Bar Operating Pressure
• Suitable for High Water Pressure System
