Jaquar Queens Prime Mono Basin Mixer Tap With Click-Clack Waste

Jaquar Queens Prime QQP-CHR-7001BPMCLW Details

Jaquar Queens Prime Mono Basin Mixer Tap With Click-Clack Waste.

Deck-mounted installation.
Supplied with click-clack waste.
Size [mm]: Ø50mm x 175mm [Width x Height].
Size [cm]: Ø5cm x 17.5cm [Width x Height].
Centre of the inlet to the centre of the outlet: 122mm (12.2cm).
Base to spout: 105mm (10.5cm).
375mm (37.5cm) Long 1/2-inch braided hoses.

Flow rate @3 bar: 14.7 lpm.
Requires a minimum of 0.5 bar to a maximum of 5 bar of water pressure for smooth working.
Soft and splash-free flow.
Wide angle of lever provides extra comfort and flawless, smooth operation.
Integrated honeycomb-structured aerator provides lime build-up protection, and the anti-clogging dome screen filters sediments and dust particles.
Refer to the technical drawing for additional size details.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Range
: Queens Prime
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Brass
⤷ Theme
: Traditional
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Base To Spout
: 105
⤷ Spout Reach
: 122

⤷ Overall Height
: 175
⤷ Width
: Ø50
⤷ Inlet Connections
: 1/2-Inch
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Water Saving
: Yes
⤷ Waste Type
: Click-Clack
⤷ Diameter of Waste Connection
: Ø66
⤷ Handle Style
: Stick Handle
⤷ WRAS Approved
: Yes
⤷ Waste Included
: Yes
⤷ Barcode
: 5057199978561
⤷ Product Type
: Basin Mixer Tap

Total: £123.19 3-4 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Bar Pressure

Bar is a unit of pressure, which is accepted for use with SI by The International Bureau of Weights and Measures. The bar is used as it is almost equal in value as the standard atmosphere which is 1.01325 bar.

Click-Clack Waste

Also called the Push button or Sprung waste, this waste needs a push down on the stopper to close and a click to open it back again. It is the most commonly used waste due to the ease of its operation.

Medium Water Pressure

Water systems operating at a pressure between 0.5 and 0.9 bar are considered medium pressure. Products usually come labelled if they are suitable for use in medium pressure.

Single Lever Taps

These taps are designed with a single lever or handle to control the water's temperature and flow. Extremely easy to operate, these also allow you to preset the water temperature by leaving it in the position with your preferred water temperature. Besides, it is simple to control the flow of water; the higher you lift the lever or move it to the end, the stronger the water flow.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
