Jaquar Queens Prime Wall Mounted Stop Valve

Finishes: Chrome, Antique Copper

£36.26

RRP: £49.00

STOCK AVAILABLITY:

3-4 Working Days Approx.

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Select Finishes
You've selected: OP-238005 - Chrome
Key Features
  • WRAS Approved
  • Ten-year warranty from the manufacturer
  • Available in 2 finishes: Chrome, Antique Copper
SKU Code: QS-V112473

MFC Code: QQP-CHR-7083PM

Jaquar Queens Prime QQP-CHR-7083PM Details

Jaquar Queens Prime Wall Mounted Stop Valve.

  • Manufactured using high-quality brass material.
  • Wall-mounted installation.
  • Backplate Size [mm]: 70mm x 85mm [Width x Height].
  • Backplate Size [cm]: 7cm x 8.5cm [Width x Height].
  • Connection: 1/2-Inch BSP.
  • Minimum-Maximum wall mount: 40-65mm (4-6.5cm).
  • The cartridge spindle is made of brass instead of plastic to avoid breakage.
  • Requires a minimum of 0.5 bar to 5 bar of water pressure for smooth operation.
  • Flow rate @ 3 bar: 47 lpm.
  • Refer to the technical drawing for more size details.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Chrome
  • ⤷ Warranty/Guarantee
  • : 10 Years
  • ⤷ Material
  • : Brass
  • ⤷ Theme
  • : Traditional
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Min-Max Wall Mount
  • : 40-65
  • ⤷ Inlet Connections
  • : 1/2-Inch
  • ⤷ Minimum Operating Pressure (Bar)
  • : 0.5
  • ⤷ Handle Style
  • : Crosshead Handle
  • ⤷ WRAS Approved
  • : Yes
  • ⤷ Backplate Width
  • : 70
  • ⤷ Backplate Height
  • : 85
  • ⤷ Number of Handles
  • : 1
  • ⤷ Plumbing Option
  • : Concealed
  • ⤷ Maximum Operating Pressure (Bar)
  • : 5

Total: £36.26 3-4 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Bar Pressure

Bar Pressure

Bar is a unit of pressure, which is accepted for use with SI by The International Bureau of Weights and Measures. The bar is used as it is almost equal in value as the standard atmosphere which is 1.01325 bar.

High Water Pressure

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

WRAS Approved Product

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
