Vado Individual Zone 2 Outlet Concealed Thermostatic Shower Valve

Vado Individual Zone IND-Z128/2-BLK Details

Vado Individual Zone 2 Outlet Concealed Thermostatic Shower Valve.

Key Features

✔Concealed valve with all-flow function
✔Fifteen-year guarantee from the manufacturer
✔Two outlet, two button shower valve with thermostatic control
✔Available in 4 finishes: Brushed Black, Brushed Gold, Brushed Nickel, Brushed Bronze

A separate on/off push button concealed stop valve module to control additional outlets is available (Optional).
For a bolder and more personalised look, customise your valve by swapping out the Halo in the middle for an alternative colour (Optional).
Manufactured using high-quality material.
Wall-mounted installation.
Handle type: Push-button..
Precision engineered to provide impeccable water temperature blending, ensuring the safety of all users for the perfect experience every time.
Temperature control encircled by an ergonomic recess.
Discreet, 4mm (0.4cm) button projection whilst in use and a slim 6mm (0.6cm) back plate to maintain the clean aesthetic.
Minimum-maximum wall mount: 80-117mm (8-11.7cm).
Connection\Fittings: 2 x 1/2-Inch female inlets and outlets.

Additional 2 x 1/2-Inch capped-off female outlets.
Includes thermostatic cartridge (V-701-32) and 2 x flow-stop-go cartridge (N-10-01-26F)..
Supplied with mortal-tile guard.
Plumbing system suitability: Combination Boiler.
Suitable for use with high-pressure water systems.
Requires a minimum of 1.0 bar water pressure for smooth working.
Refer to the technical drawing for complete dimensional details.
For flow rates, refer to the additional image.
Download the Installation Instructions PDF file from the Additional Info section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Brushed Bronze
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Min-Max Wall Mount
: 80-117
⤷ Inlet Connections
: 1/2-Inch
⤷ Minimum Operating Pressure (Bar)
: 1.0
⤷ Handle Style
: Push Button
⤷ Temperature Control
: Thermostatic

⤷ Backplate Width
: 121, 248
⤷ Backplate Height
: 248, 121
⤷ Number of Handles
: 2
⤷ Number of Outlet
: 2
⤷ Orientation
: Portrait, Landscape
⤷ Barcode
: 5052120276716
⤷ Product Type
: Thermostatic Shower Valve
⤷ Plumbing System Compatibility
: Combination Boiler
⤷ Plumbing Option
: Concealed

Additional Info & Downloads

Download the Installation Instruction Pdf File

Technical Images

Vado Individual Zone 2 Outlet Concealed Thermostatic Shower Valve

Total: £746.26 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Combi-Boiler System

The showerhead or shower system is suitable for use with a Combi-Boiler System. This system heats cold water on demand, relying solely on mains pressure to move water around your home. These are suitable for mixer showers, as they provide hot water instantaneously and at the highest pressure.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

All Flow

The All flow function within the shower valves enables the water to flow to either individual shower outlets or all outlets simultaneously.
