Vado Phase Chrome Mono Basin Mixer Tap

Vado Phase PHA-200FW/SB-CP Details

It is simply the best, this Basin Mixer Tap from the house of Vado. The product comes to you from the brands Phase range and features ceramic disc technology and an EcoTurn cold start cartridge. It is suitable for low-pressure water systems and offers a flow rate of 5.1 l/min at 3 bar pressure. The model, attractive in chrome finish, is guaranteed against all manufacturing defects for 15 years. Order it from your favourite online store for a fantastic discount and fast delivery.

The deck-mounted model comes in 2 variations, with and without waste. You will be happy to know that besides all of the above features, what makes it an excellent purchase is that it also includes a water-saving H2Eco flow regulator that precisely regulates the flow and, therefore, consumption, helping you save lots of bucks annually.

Available in 2 variations: Tap Only, Tap With Universal Waste.
Deck mounted installation.
Size [mm]: 40mm x 145mm x 159mm [Width x Depth x Height].
Size [cm]: 4cm x 14.5cm x 15.9cm [Width x Depth x Height].
Centre of the inlet to centre of outlet: 105mm (10.5cm).
Base to spout: 100mm (10cm).
Ceramic cartridge: C-001-C35.

2 x 1/2 inch 400mm (40cm) Flexi pipe connections.
Deck mount drill hole diameter: 35mm (3.5cm).
Requires minimum 0.2 bar operating pressure.
Suitable for low water pressure system.
Flow rate at 3 bar pressure: 5.1l/min.
Refer to the technical image for more dimensional details.
Download the Installation Instruction PDF File from the Additional Info Section.

Info / Size (mm)

Tap
Width: 40 mm
Depth: 145 mm
Height: 159 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Range
: Phase
⤷ Tap Body Shape
: Square
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Ceramic Disc

⤷ Base To Spout
: 100
⤷ Spout Reach
: 105
⤷ Overall Height
: 159
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Waste Type
: Universal Waste
⤷ Flow Rates (l/min)
: 5.1 - 3.0 bar
⤷ Handle Style
: Lever Handle
⤷ WRAS Approved
: Yes
⤷ Deck Mount Drill Hole Diameter
: 35
⤷ Waste Included
: Sold Separately
⤷ Compliance/Approvals/Standard
: WRAS
⤷ Barcode
: 5052120253991
⤷ Product Type
: Basin Mixer Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £162.50 3-4 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...
