Armitage Shanks Markwik 21+ 2 Hole Thermostatic Basin Mixer Tap With Bioguard

Armitage Shanks Markwik A6734AA Details

The Armitage Shanks Markwik 2 Hole Thermostatic Basin Mixer Tap with Bioguard is constructed from strong and durable brass material and coated in a chrome finish that provides it with a versatile look that fits in well in any bath set-up. Suitable for use within low- and high-pressure water systems, this unit also offers a flow rate that can be regulated to a maximum of 10 litres per minute. Recommended for general healthcare use, this unit boasts a bio guard against bacteria as well as a thermal disinfection feature. TMV3 and WRAS approved, this model can also include a purging kit if chosen as an option.

Fixed spout.
It comes in a chrome finish.
Weight: 4kg.
Height: 271mm [27.1cm].
Base to spout: 152mm [15.2cm].
Centre of the inlet to the outlet: 170mm [17cm].
Width: 28mm [2.8cm].
Inlet centres: 200mm [20cm].

Conforms to HBN 04-01 Addendum 2014.
Demount, submerge and disinfect.
Bioguard against bacteria.
Thermal disinfection feature.
It can be used with two tap-hole basins.
Suitable for high and low-pressure systems.
The flow rate is regulated to a maximum of 10 litres per minute.
Purging kit [See Option].

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Markwik 21+
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 2
⤷ Spout type
: Fixed
⤷ Handle Material
: Brass

⤷ Base To Spout
: 152
⤷ Inlet Centres
: 200
⤷ Overall Height
: 271
⤷ Width
: 258
⤷ Max. Deck Thickness
: 50
⤷ Flow Rates (l/min)
: 10 Ltr/minute
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes
⤷ Deck Mount Drill Hole Diameter
: 50
⤷ Compliance/Approvals/Standard
: TMV3 / WRAS
⤷ Barcode
: 4015413339674
⤷ Product Type
: Commercial Basin Tap

Customise Your Product

Optional-Accessories

Available optional accessories. Please Note: The image is for illustration purpose only.

No Option Selected
OP-130195 - Purging kit + £46.85

Total: £655.44 2-3 Working Days Approx QS Supplies

5 Features Included In This Product Explained

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

TMV3 Approved Product

TMV3 approval means a thermostatic valve is certified and approved for use in healthcare and commercial situations.

BioGuard

Yet another feature developed by Armitage Shanks for maintaining bathroom hygiene, Bioguard is a patented copper-lined outlet. It helps in the control of pseudomonas infection.
