Nuie Arvan Square Thermostatic Bar Valve And Shower Kit

Nuie Arvan JTY486 Details

Bring in a classy addition to your bathroom with the installation of the Arvan Square Thermostatic Bar Valve and Shower Kit, which comes to you from the house of Nuie. The fascinating creation is designed meticulously in a minimalist planate design and can be purchased in one of 3 finish choices of Matt Black, Brushed Brass and Brushed Gun Metal.

The product includes a thermostatic bar valve, shower head, handset and hose. The valve is ideally fabricated to work well with medium-pressure systems and is concealed in installation. The durable metal and ABS construction are covered with a 5-year guarantee against manufacturing defects. Get excited about multi-option showering with this product installed within your enclosures.

No of outlets: 2.
Handset Function: Single Setting.
Overall size [mm]: 263mm x 526mm x 848-1328mm [Width x Depth x Height].
Overall size [cm]: 26.3cm x 52.6cm x 84.8-132.8cm [Width x Depth x Height].
Pipe centre: 150mm (15cm).
Pipe size: 15mm (1.5cm) (1/2inch BSP).
Flow Rates (L/min): 0.5 bar: 3, 1 bar: 5, 2 bar: 9, 3 bar: 12.
Compatible with shower pumps.
The perfect solution to multi-option showering.
Shower Head:.
Single head function.
Width: 200mm (20cm).

Bar Valve:.
1/4 Turn ceramic disc cartridge.
Mounted type: Wall and Surface.
Size [mm]: 263mm x 35mm [Width x Height].
Size [cm]: 26.3cm x 3.5cm [Width x Height].
Suitable for medium water pressure system.
Requires 1.0 bar water pressure.
Thermostatic control to +/- 2 degrees even if the water pressure fluctuates.
In the event of water failure, the valve will shut down the water supply and prevent scalding.
Suitable for unvented mains pressure systems.
Download the Customer Data Sheet and Fitting Instruction PDF File from the Additional Info Section.
The technical drawing is available for more technical details.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Matt Black
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass and ABS
⤷ Theme
: Modern
⤷ Minimum Operating Pressure (Bar)
: 1.0
⤷ Hose Included
: Yes

⤷ Riser Rail & Kit Finish
: Matt Black
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: Single
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: 200

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Fitting Instruction Pdf File

Total: £153.19 2 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Unvented System

The unvented water systems usually have a separate hot water cylinder, which is pre-heated via a combi boiler or other heating sources to store a quantity of hot water at mains pressure.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
