Vado Life Concealed 1 outlet 2 Handle Chrome Thermostatic Shower Valve

Vado Life Details

MFC: LIF-148D-C/P

Enjoy your showers at a precise temperature preferable to your tastes when you use the Vado Life Concealed 1 outlet 2 Handle Thermostatic Shower Valve. The valve features an oval back-plate that measures 146 millimetres in width by 226 millimetres in height and can easily fit onto any shower wall. On the wall-mounted back-plate are two thermostatic valves that you can use to adjust the water temperature with great precision to ensure the most comfortable shower possible. A dazzling chrome finish gives the valve a remarkable shine that is resistant to stains. To complete your bathroom design, pair it with a matching chrome-plated riser rail kit.

Key Features

✔It comes in a Chrome Finish
✔Thermostatic Cartridge: V-001C-PLA
✔Includes Bleed Valve for System Flush on Installation
✔15-Year Guarantee from the Manufacturer

Choice of Variants: 1 Outlet, 2 Outlets, 3 Outlets
Wall-Mounted Installation
Oval Back-Plate
Minimum Operating Pressure: 0.2 Bar - Low Pressure [Shower], 1.0 Bar - High Pressure [Bath]
Size [mm]: 146 x 226mm [Width x Height]
Size [cm]: 14.6 x 22.6cm [Width x Height]
Includes 3/4-Inch - 1/2-Inch Adaptors
Minimum-Maximum Wall Mount: 70-95mm (7-9.5cm)
Optimum Installation Depth: 82mm (8.2cm)
Studfast Concealed Shower Valve Mounting Brackets [See Option]
Refer to the Technical Diagram for more Technical Details
Download the Installation Instruction PDF File from the Additional Info Section
Specification For 1 Outlet:
2 x 3/4-Inch Female Inlets
1 x 3/4-Inch Female Outlet
Flow Cartridge: C-301-RTC
Specification For 2 Outlets:
With Integrated Diverter
2 x 3/4-Inch Female Inlets
2 x 3/4-Inch Female Outlet
Diverter Cartridge: FL-804-33X/3X
Specification For 3 Outlets:
With Integrated Diverter
2 x 3/4-Inch Female Inlets
3 x 3/4-Inch Female Outlet
Diverter Cartridge: FL-804-33X/3X

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Shape
: Oval
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Min-Max Wall Mount
: 70-95mm
⤷ Inlet Connections
: 3/4-Inch
⤷ Minimum Operating Pressure (Bar)
: 0.2 [Low-Pressure - Shower], 1.0 [High-Pressure - Bath]
⤷ Handle Style
: Knob

⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 146
⤷ Backplate Height
: 226
⤷ Number of Outlet
: 1, 2, 3
⤷ Outlet Connection
: 3/4-Inch
⤷ Plumbing Option
: Concealed
⤷ Concealed Body Included
: Yes
⤷ Cartridge Included
: Yes

Additional Info & Downloads

Download the User Guide & Care Instruction Pdf File Download the Installation Instruction Pdf File Download the Installation Guide 1 Outlet Pdf File Download the Installation Guide 2 Outlet Pdf File Download the Installation Guide 3 Outlet Pdf File

Add-Ons

Studfast Brackets

The Studfast is an easy, secure and robust method of mounting thermostatic shower valves into stud walls to create a firm and trouble-free installation. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-44782 - Studfast Concealed Wall Bracket + £40.16

Videos

Video of Attaching A Shower Valve And Fitting To The Wall Stud

Vado Life Concealed 1 Outlet 2 Handle Thermostatic Shower Valve

£383.80

RRP: ~~£575.00~~

STOCK AVAILABLITY: 3 Working Days Approx

QS Supplies

5 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Darren Asked :
Hi, Could you please tell me the dimensions of the shroud/backplate, including the depth?

Answered By QS Team

Please see the attached installation instruction PDF file for the information you require.

Was this answer helpful?
