Geberit Monolith Sanitary Module 480 x 1010mm For Wall-Hung WC

Technical drawing QS-V93585 / 131.021.SL.5

Additional image of Geberit 131.021.SL.5

Additional image of Geberit Monolith Sanitary Module 480 x 1010mm For Wall-Hung WC

Additional image for QS-V93585 Geberit - 131.021.SL.5

Geberit Monolith Sanitary Module 480 x 1010mm For Wall-Hung WC small Image 4

Geberit Monolith Sanitary Module 480 x 1010mm For Wall-Hung WC

More Finishes Available

QS-V93585

MFC CODE: 131.021.SL.5

£595.92

RRP: ~~£1157.34~~

STOCK AVAILABILITY

3-4 Working Days Approx

No Rating

Review this Product

Shipping: £15.00

Variations

Technical

Select Finishes Available

OP-112933 - Mint Glass - 131.021.SL.5

+ Read what's included.. & options available

Please Note all the measurements are in 'mm'

Colour	Mint Glass
Country of Origin	Germany
Material	Glass
Flush Type	Dual Flush
Full Flush Volume in litres	6
Half Flush Volume in litres	3
Width	480
Height	1010
Water Supply Connections	Bottom, Left or Right

INFO / SIZE (mm)

+ Other Sizes & Variations Available

Frame
Width: 480 mm
Height: 1010 mm

QTY

Geberit Monolith 131.021.SL.5 DETAILS

The Geberit Monolith Sanitary Module for WC is available in several different finish options to choose from and is ideal for installation within renovations, conversions, and new buildings of all kinds. Height adjustable up to 7cm and self-supporting, this product includes flush volume factory settings of 6 and 3-litres, which can be adjusted if needed. With a front-cladding made of glass that is both thick and sturdy, the side-cladding is created from brushed aluminium, and the water supply connection is located on the bottom for an easy and secure connection.

Available in different finishes [Optional]
Glass thickness 8mm
Mint colour glass thickness 6mm
Features Dual flush
Compensation of dimensional tolerances possible
Height-adjustable up to 7 cm
Front cladding made of glass (ESG)
Fastening height WC ceramic appliance 35 ± 1 cm
Cistern fully insulated against condensation
Side cladding made of aluminium brushed
Self-supporting
Adjustable flush volume
Water supply connection on the bottom
Water supply connection on the left/right possible with accessories
Flow pressure 0.1-10 bar
Maximum operating temperature, water 25 °C
Flush volume factory setting 6 and 3 l
Flush volume large adjustment range 4.5 / 6 l
Flush volume small 3 l
Water supply Side connection Set [Optional]
Vario Fastening Set [Optional]
Please refer installation instructions PDF from below

Application purposes
For renovations, conversions and new buildings
For wall inlets with inlet height > 23 cm
For replacing low-level exposed cisterns
For replacing wall-hung WCs with close-coupled exposed cistern
For Geberit AquaClean WC complete solutions
For connecting Geberit AquaClean WC enhancement solutions, with accessories
For mounting on finished floors
For installation in front of drywalls or solid walls
For compensating the offset between WC connections and wall drains using a stepped straight connector for wall-hung WCs
Scope of delivery
Water supply connection set with 2 angle stop valves, 1/2"
Flush bend extension 160 mm
Sleeve made of EPDM, Ø 44 / 55 mm
Straight connector made of PE-HD, Ø 90 mm
Adaptor socket made of PE-HD, Ø 90 / 110 mm
2 threaded rods M12
Sound insulation set
Base cover
Fastening material for drywall
Fastening material.

CUSTOMISE YOUR PRODUCT

Water Supply Connection

Lateral Water Supply Connection Set For WC for left or right-hand installation, from Geberit Monolith.

None
OP-142453 - Lateral Water Supply Connection Set For WC + £72.11

OTHER SIZES / FINISHES

Other Sizes / Finishes / Variations Available.

QS Code	Finish	Size / Difference	MFC Code
QS-V93584	-	For Floor Standing WC	131.002.SL.5

Back to QS-V93585 / MFC CODE: 131.021.SL.5

ADDITIONAL INFO

Download the Installation Instruction Pdf File

PRODUCT VARIATIONS INFO & MFC CODE

Available Finishes Along With Manufacturing Code:
Mint Glass - 131.021.SL.5
White Glass - 131.021.SI.5
Black Glass - 131.021.SJ.5
Sand Glass - 131.021.TG.5
Umber Glass - 131.021.SQ.5.

Total: £595.92 3-4 Working Days Approx QS Supplies

Add-on Selected: Total Price Now:

You May Also Require

REVIEWS & RATINGS

Rate this Item.:

WRITE A REVIEW

Questions & Answers

Submit Your Questions 2 Questions Asked

Have a question about this item? Ask our tech team. We aim to reply within 72 hours. If you want to know get answers fast, please call us on 0116 251 0051

Tracey Asked :

What wall hung toilet is comparable with this

Answered By QS Team :
Please see the dimensions of the pan you are purchasing: Distance between the centres of the flush pipe and the soil pipe should be 135mm. The fixing bolts that hold the pan to the wall should be either 180mm or 230mm apart.

Was this answer helpful? -
