Burlington Trent Thermostatic Dual Outlet Diverter Valve With Shower Set



2-3 Working Days Approx.

4.0 out of 5 4.0 out of 5

Based on 1 Ratings.

Shipping: £7.95

Product Variants
Select Shower Set Finish Step 1
Select Accent Finish Step 2
Select Rose Size Step 3
SKU Code: QS-V10842

MFC Code: TF2S BLA+V16

Burlington Trent TF2S BLA+V16 Details

The Burlington Trent Thermostatic Dual Outlet Diverter Valve with Shower Set is a versatile and practical unit, realised in the classic period style. The two outlets can be easily operated via the integrated diverter valve, and quickly changing between the overhead unit and the separate hand shower can be easily done. Ceramic lever and Claremont handle to provide control over water flow and temperature.

To ensure a safe and comfortable showering experience, this unit includes a thermostatic cut-off to prevent scalding if the cold water feed fails. The Airburst head with an adjustable shower arm will provide an invigorating and refreshing experience each time the user turns on the tap. The package also includes a handset, hose, wall outlet elbow and adjustable wall bracket to complete your shower unit.

Key Features
  • Available in 2 shower set finishes: Chrome, Gold
  • WRAS Approved
  • Features anti-limescale nozzles
  • Fifteen years of guarantee from the manufacturer
  • Body constructed from brass
  • 3 Accent finishes available: Black, White, Medici.
  • Available rose sizes: 6-inch, 9-inch, 12-inch.
  • Traditional design.
  • Product Includes:.
  • Dual outlet concealed thermostatic diverter valve included.
  • Airburst shower head.
  • It comes with a 390mm (39cm) adjustable fixed shower arm.
  • Complete with wall outlet, 1500mm (150cm) hose, adjustable wall bracket, and handset with ceramic handle.
  • Valve specification:.
  • It comes complete with a traditional brass faceplate, Claremont handle and ceramic lever.
  • Also available with Anglesey and Birkenhead handle optional [See Option].
  • Thermostatic safety - The temperature of your shower will not vary by more than +/- 1°C - even if someone flushes a WC whilst you are showering.
  • Minimum operating pressure required: 3.0 bar [High Pressure].
  • Size [mm]: 120mm x 82mm x 259mm [Width x Depth x Height].
  • Size [cm]: 12cm x 8.2cm x 25.9cm [Width x Depth x Height].
  • Showerhead specification:.
  • Made from ABS or ABS/Brass.
  • AirBurst Built-in [more power, less water - saves water without ruining your shower].
  • Features anti-limescale nozzles - simply rub your fingers over the silicon tips, and the limescale is removed.
  • For the complete size, detail refer to the technical drawing.
  • Download the Installation Instruction PDF File from the Additional Info section.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Chrome
  • ⤷ Weight in kg
  • : 4.73
  • ⤷ Warranty/Guarantee
  • : 15 Years
  • ⤷ Material
  • : Brass
  • ⤷ Valve Included
  • : Yes
  • ⤷ Valve/Cartridge Type
  • : Concealed
  • ⤷ Minimum Operating Pressure (Bar)
  • : 3.0
  • ⤷ Water Saving
  • : Yes
  • ⤷ Hose Included
  • : Yes
  • ⤷ Hose Length
  • : 1500
  • ⤷ Flow Rates (l/min)
  • : 0.2 bar - 3.85, 0.5 bar - 4.45, 1 bar - 7.25, 2 bar - 10.85, 3 bar - 12.3
  • ⤷ Configuration
  • : Valve With Head And Shower Kit
  • ⤷ Temperature Control
  • : Thermostatic
  • ⤷ Diverter Included
  • : Yes
  • ⤷ Handset Included
  • : Yes
  • ⤷ Valve Size
  • : W 120 x H 259
  • ⤷ Shower Head Included
  • : Yes
  • ⤷ Shower Head Size
  • : Ø 180

Additional Info & Downloads

Download PDF Download the Valve Installation Instructions Pdf File Download PDF Download the Shower Head Installation Instructions Pdf File

Technical Images

Customise Your Product

Optional Handles
Optional Handles

Anglesey and Birkenhead handle available as optional. The image shown is for illustration purposes only.

Burlington Optional Extras
Burlington Optional Extras

Slide rail can be ordered as extras. Please Note: The image is for illustration purpose only.

Total: £498.17 2-3 Working Days Approx QS Supplies

6 Features Included In This Product Explained



A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.

Thermostatic Control

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.

Airburst Shower Head

Airburst Shower Head

The Airburst system mixes water and air in Burlington Bathroom shower heads to give you a feeling of increased water pressure while saving up to 33% of the water used with a traditional showerhead.

WRAS Approved Product

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.

Easy Clean Nozzles

Easy Clean Nozzles

Shower heads and handsets can be easily cleaned with a damp cloth, preventing limescale build-up.

High Water Pressure

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
