Armitage Shanks Contour 21 Back-To-Wall WC Pan For School 305mm High

£211.51

STOCK AVAILABILITY

2-3 Working Days Approx

4.5 out of 5 4.5 out of 5

Based on 2 Ratings.

Shipping: £20.00

Key Features
  • Made from top quality vitreous china material
  • Comes with a horizontal outlet
  • Supplied with open flushing rim
  • Water-efficient modern design
  • Lifetime guarantee from the manufacturer against any manufacturing defects
SKU Code: QS-V10122

MFC Code: S304601

Armitage Shanks Contour S304601 Details

Armitage Shanks brings you Contour 21 Back-To-Wall WC Pan especially designed for children between the ages of three and six years. Ideal for schools, play areas, and in public utilities, it is crafted from white vitreous china and carries a lifetime guarantee from the company against manufacturing flaws, if any. The pan can be screwed to the floor and comes with open flushing rim. Easy to install it comes as a boon for both parents and children.

  • Suitable for younger children in schools or public areas [age 3-6 years].
  • Comes in white finish.
  • The manufacturing code of this product is S304601.
  • The seat ring shown in the image is not included - sold separately.
  • Size [mm]: 315mm x 305mm [Width x Height].
  • Size [cm]: 31.5cm x 30.5cm [Width x Height].
  • Projection from wall: 490mm [49cm].
  • Pan screwed to the floor.
  • For complete size details, please refer to the technical drawing.
  • Available Options.
  • Concealed Cistern.
  • Flush Button.
  • Toilet Seat and Cover.
  • Domex Screw.

Info / Size (mm)

  • Toilet
  • Width: 315 mm
  • Projection: 490 mm
  • Height: 305 mm

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : White
  • ⤷ Country of Origin
  • : EU
  • ⤷ Warranty/Guarantee
  • : Lifetime
  • ⤷ Material
  • : Vitreous China
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Floor Mounted
  • ⤷ Projection (Depth)
  • : 490
  • ⤷ Width
  • : 315
  • ⤷ Outlet
  • : Horizontal
  • ⤷ Comfort Height
  • : Yes
  • ⤷ Configuration
  • : Bowl Only
  • ⤷ Height
  • : 305
  • ⤷ Rough In
  • : 165
  • ⤷ Seat Included
  • : Sold Separately
  • ⤷ Barcode
  • : 5057199961631
  • ⤷ Bowl Shape
  • : Round
  • ⤷ Cistern Depth (projection)
  • : 150
  • ⤷ Base width
  • : 185
  • ⤷ Base Depth (projection)
  • : 385
  • ⤷ Pan fixing centres
  • : 120
  • ⤷ Cistern Fixing Centres
  • : 210
  • ⤷ Outlet Diameter
  • : 102
  • ⤷ Base to centre of outlet
  • : 180

Customise Your Product

Optional Cistern
Optional Cistern

The cistern is now available for your WC. Please note image shown is for illustration purpose only.

Flush Plate
Flush Plate

Flush Plate Please note: the image shown is for illustration purpose only.

Toilet Seat / Ring
Toilet Seat / Ring

Optional toilet seat from Armitage Shanks with different finishes from options given below! Please note: The image is for illustration purposes only.

Domex Screws
Domex Screws

Fine quality fixing screws for multi-purpose use from Armitage Shanks. Please note: Image is not available.

Total: £211.51 2-3 Working Days Approx QS Supplies

2 Features Included In This Product Explained

Horizontal Outlet

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Vitreous-China Material

Vitreous-China Material

It is a compound of glass and silica-based materials applied as a coat on porcelain products such as WC pans, urinals, baths and basins to protect them from scratches and stains as an anti-vandal measure.
