Armitage Shanks Contour 21+ 1 Hole Thermostatic Basin Mixer Tap

Armitage Shanks Contour A6697AA Details

The Armitage Shanks Contour 21+ 1 Hole Thermostatic Basin Mixer Tap is constructed from chrome-plated brass material and is suitable for use with high and low-pressure water systems. TMV3 and WRAS approved, this product is designed for installation upon any standard pillar tap hole and includes 15mm compression connections and anti-vandal laminar flow outlet. Designed for commercial and Doc M use, this unit also includes an integral thermostat as well as a single lever for simple on/off operation and temperature control. A water-saving model that boasts three unique clamping rings with fixing screws for added security.

It comes in a chrome finish.
Weight: 2.1kg.
Height: 143mm [14.3cm].
Base to spout: 42mm [4.2cm].
Centre of the inlet to the outlet: 110mm [11cm].
Water-saving.
Integral thermostat.

Eliminates the need for premixed water.
Standard pillar tap hole.
Single sequential lever for on/off operation and temperature control.
15mm Compression connections.
Suitable for high and low-pressure systems.
Clamping ring with three fixing screws for added security.
Five years of guarantee from the manufacturer against any manufacturing defects.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Contour 21+
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Handle Material
: Brass

⤷ Base To Spout
: 42
⤷ Spout Reach
: 110
⤷ Overall Height
: 143
⤷ Max. Deck Thickness
: 55
⤷ Minimum Operating Pressure (Bar)
: 3
⤷ Water Saving
: Yes
⤷ Flow Rates (l/min)
: 3 bar - 3.9 Ltr
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes
⤷ Deck Mount Drill Hole Diameter
: 51
⤷ Compliance/Approvals/Standard
: TMV3 / WRAS
⤷ Barcode
: 4015413340120
⤷ Product Type
: Commercial Basin Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £409.98 2-3 Working Days Approx QS Supplies

7 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

TMV3 Approved Product

TMV3 approval means a thermostatic valve is certified and approved for use in healthcare and commercial situations.

Temperature control

The Thermostatic mixers come with a temperature control mechanism which saves temperature that stays constant at all times. Some of the mixers from the company come with a control button with a pre-set temperature of 40°C(minimum) so that you can save on your energy bills.

Doc-M Pack

A Doc M pack is an assortment of sanitary ware compliant with disabled washroom provisions in Document M of the UK Building Regulations. These Doc M regulations apply to new commercial spaces but can also be installed in older buildings. People with disabilities may need to use washrooms in different kinds of buildings-both old and new. Doc M makes it very easy for those with disabilities who are wheelchair-bound. These packs are comforting and offer ease of use for wheelchair-bound and elderly users, also come with ergonomic design and attractive colours.

Single Lever Taps

These taps are designed with a single lever or handle to control the water's temperature and flow. Extremely easy to operate, these also allow you to preset the water temperature by leaving it in the position with your preferred water temperature. Besides, it is simple to control the flow of water; the higher you lift the lever or move it to the end, the stronger the water flow.
