Armitage Shanks Contour 21 Handrinse Washbasin 370mm Centre Tap Hole

Armitage Shanks Contour Details

MFC: S212201

Designed for a lifetime of performance and enjoyment, the Contour 21 Handrinse Washbasin, brought to you by Armitage Shanks. This fabulous bathroom adornment with its sleek slender and defined contour imparts a futuristic look to the bathroom. The pure white finished creation in vitreous china withstands the test of time and serves for many years. This wall-mounted product is suitable to use in public areas, special care applications like children, older people, ambulant disabled and infirm people.

Key Features

✔Appropriate for Doc M Application
✔Short Projection Washbasin
✔Constructed Using Vitreous China to BS 3402
✔Comply with BS EN 14688 & BS EN 31
✔Guarantee of 5 Years from the Manufacturer Against any Manufacturing Defects.

Size [mm]: 370mm x 300mm [Length x Width]
Size [cm]: 37cm x 30cm [Length x Width]
Pure White Finish
The Manufacturing Code of this Product is S212201
It Comes with an Integrated White Bottom Outlet
Supplied Without Overflow and Chain-Stay Hole
Suitable for Wall Mount Installation
Suitable to Use in Public Areas and Special Care Applications like Children, Elderly People, Ambulant Disabled, and Infirm People
Recommended Fixing Height [Floor to Front Rim]
Nursery Use - 600mm [60cm]
Infant Use - 700mm [70cm]
Junior Use - 750mm [75cm]
Senior/Adult Use - 780-800mm [78-80cm]
Designed by Robin Levien
Also Available in Right-Hand Tap Hole and Left-Hand Tap Hole
Steel Concealed Hanger
Waste 1 1/4 Inch Brass Strainer Waste, 80mm Un-Slotted Tail
Trap 1/4 Inch Metal Bottle, 75mm Seal, Outlet Screwed 1/4 Inch BSP Male with Compression Nut and Ring
Tap, Waste and Trap Shown in the Image are Not Included

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: White
⤷ Shape
: Rounded Rectangular
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: Lifetime
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Projection (Depth)
: 305
⤷ Width
: 370
⤷ Height
: 165
⤷ Fixings included
: Sold Separately
⤷ Distance between centre holes
: 105

⤷ Inner Bowl Width
: 305
⤷ Inner Bowl Depth
: 150
⤷ Distance rear edge to centre of waste hole
: 160
⤷ Fixing Holes Centre
: 225
⤷ Distance rear edge to centre of tap hole
: 55
⤷ Number of bowls
: 1
⤷ No. of Tap Holes
: 1
⤷ Tap Hole Position
: Centre
⤷ Overflow Included
: No
⤷ Brassware Included
: No
⤷ Chainstay hole
: No

Add-Ons

Optional Siphon And Waste

A Compatible siphon or waste that Duravit highly recommends. Please note - The image shown is for illustration purpose only.

No Option Selected
OP-43047 - 1.25 Inch Brass Strainer Waste - 80mm Un-slotted Tail RECOMMENDED
+ £41.30

Waste & Trap

Strong and durable waste or traps from Armitage Shanks - Ideal Standard to choose from options. Please note: The image shown is for illustration purpose only.

OP-56815 - 1.25 Inch Metal Bottle Trap - 75mm Seal With Nut And Ring + £55.98

Concealed-Hangers

Concealed hangers. Please note image shown is for illustration purpose only.

No Option Selected
OP-43051 - Concealed steel hangers RECOMMENDED
+ £9.62

Armitage Shanks Contour 21 Small Handrinse Washbasin 370mm Centre Tap Hole

£105.23

RRP: ~~£163.68~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

4 Features Included In This Product Explained

Vitreous-China Material

Vitreous china is an innovative glass-based enamel coating applied to porcelain. This glazed coating makes the base material durable, denser, and very glossy. When ceramics are coated with vitreous enamel, the resulting product is called vitreous china. This enamel is created by applying heat to powdered glass.

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called 'without-overflow' and will need a compatible drain.

DOC M

It is an assortment of sanitary ware compliant with disabled washroom provisions in Document M of the UK Building Regulations. These regulations apply to new commercial spaces but can also be installed in older buildings. People with disabilities may need to use washrooms in different kinds of buildings-both old and new. These packs are comforting and offer ease of use for wheelchair-bound and elderly users, and also come with ergonomic design and attractive colours.

BSP Male Connector

British Standard Pipe (BSP) are a group of internationally accepted standards for threads for interconnecting hoses and fittings by mating an external (male) thread with an internal (female) thread. A BSP male connector also called Plug is a kind of threaded fitting used in plumbing and piping systems. It comes attached to a wire or hardware, has an exposed electrical terminal which fits into a receptacle (called female connector to complete the electrical connection.
