Bristan Gummers Opac Thermostatic Exposed Shower Valve

Technical drawing QS-V78223 / OP TS1503 SCL C

Bristan Gummers Opac Thermostatic Exposed Shower Valve - OP TS1503 SCL C

QS-V78223

MFC CODE: OP TS1503 SCL C

£287.70

RRP: ~~£500.00~~

STOCK AVAILABILITY

2 Working Days Approx

4.5 out of 5

2 out of 2 customers rated 90%

Review this Product

Shipping: £6.95

Description

Technical

Compact and competent, the Gummers Opac Thermostatic Exposed Shower Valve from Bristan, comes complete with a chrome-lever and ABS protective shroud, to prevent scalding; all polished to brilliant chrome and suitable for all plumbing systems. Easy to install with instructions from Technical Tab, the shower valve made of high-grade brass, excellently caters your showering needs.

+ Read what's included..

Please Note all the measurements are in 'mm'

Colour	Chrome
Warranty/Guarantee	1 Year
Material	Brass
Theme	Modern
Installation Type	Wall Mounted
Minimum Operating Pressure (Bar)	0.2
Handle Style	Lever
WRAS Approved	Yes
Temperature Control	Thermostatic
TMV3 Approved	Yes
Number of Handles	1
Outlet Connection	1/2"
Plumbing Option	Exposed
Maximum Operating Pressure (Bar)	8
Cartridge Included	Yes
Cartridge Type	Thermostatic

QTY

Bristan Gummers OP TS1503 SCL C DETAILS

Completes with chrome lever and shroud
Comes in attractive chrome finish
Chrome plated to BS EN 248
Manufacturing code of this product : OP TS1503 SCL C.
Constructed using solid brass
Designed to conform to BS EN 1111:19999 [HP] and BS EN 1287:1999 [LP]
Suitable for all type of plumbing installation
Commercial shower valve
15mm compression elbow of inlet connections
1/2" Inch BSP of outlet connections
Thermostatic cartridge
Single sequential control for both flow and temperature

Required minimum 0.2 bar to maximum 8.0 bar water pressure
Suitable for low water pressure
Static pressure required : maximum 10.0 bar
ABS protective shroud for safe surface temperature
Refer technical image for technical dimension
Features automatic thermostatic system that turn off the valve in case of hot or cold water supply failure
Valves and Serviceable filters are checked as standard
WRAS Certificate Number : 0712092
TMV3 Certificate Number : BC397/1208
Download PDF file for fitting instruction from technical tab
1 year of guarantee from Bristan against any manufacturing defects

ADDITIONAL INFO

Download the Installation Guide Pdf File

Total: £287.70 2 Working Days Approx QS Supplies

You've Selected which adds to a total of

You May Also Require

REVIEWS & RATINGS

Here's what people are saying about this item.

Rate this Item.:

Hide All Reviews

Paul FERRYHILL Date: September 29, 2020

Great

Fitted two replacements in a care home as well as looking good a very prompt delivery service easy to fit and after looking all over the place this was the only place that had the stock would recommend the company and product.

Helpful?

OVERALL RATING 4 Stars
