Duravit Qatego 1800 x 800mm Double-Ended Built-In Acrylic Whirlpool Bath

Duravit Qatego 760614000AS0000 Details

Duravit Qatego 1800 x 800mm Double Ended Built In Acrylic Whirlpool Bath.

Key Features

✔Double Ended Bath
✔Type of installation: Built in
✔Designed by Studio F. A. Porsche
✔Constructed using sanitary acrylic
✔Five-year warranty from Duravit against manufacturing defects

Whirlpool System: Air-System, Jet-System And Combi-System E [Optional].
Shape: Rectangular.
Capacity of bath: 280 Litres.
Two backrest slope on Left or Right hand of bath.
Depth: Internal 460mm (46cm) and External 480mm (48cm).
It comes in a White Alpin finish.
Refer technical drawing for more technical specification.
Available optional product.
Quadroval Waste and Overflow with Tub Filler.
Quadroval Waste and Overflow with Base inlet.
Bathtub Anchor.
Tile Flange.
Tub Heating.
Features of Air-System.
12 Drilled floor air jets (Standard).
Support Frame.
Waste and Overflow included.
Control Element - Piezo floor jets.

Features of Jet-System.
6 flat, Adjustable Standard jets (Mixture of Air and water).
Support Frame.
Waste and Overflow included.
Features of Combi-System E.
Standard 6 flat, adjustable side jets (Mixture of Air and water).
Standard 12 flat, adjustable floor jets (Air).
Standard 4 flat, adjustable back jets (Mixture of Air and water).
2 Spot, LED white light.
Standard 2 flat, adjustable foot jets (Mixture of Air and water).
Waste and Overflow included.
Support Frame.
Diverter.
Pump performance can be concentrated to foot or back jets.
Control panel with chromed brass frame and blue backlit symbols. By pressing the desired symbol, the functions starts and the symbol is blue backlit.
Download Customer datasheet and Installation Instruction PDF from the Additional Info section.
Images Shown is for illustration Purpose only.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Bath Type
: Airpool
⤷ Position of Drain
: Middle
⤷ Range
: Qatego
⤷ Interior Shape
: Rounded Rectangular
⤷ Coating
: Standard
⤷ External Length
: 1800
⤷ External Width
: 800
⤷ Tub Depth
: Internal: 460 | External: 480
⤷ Colour
: White Alpim
⤷ Internal Bottom Length
: 1131
⤷ Internal Bottom Width
: 387
⤷ Internal Top Length
: 1700
⤷ Internal Top Width
: 670
⤷ Height of Rim
: 25
⤷ Distance Tub edge to centre of drain hole
: 900

⤷ Distance Top edge to centre of overflow hole
: 97
⤷ Diameter of Drain hole
: 52
⤷ Rim Width
: 65 | 50
⤷ Weight in kg
: 37
⤷ Shape
: Rectangular
⤷ Capacity in litres
: 280
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Sanitary Acrylic
⤷ No. of Bathers
: 2
⤷ Theme
: Modern
⤷ Bath Therapy Type
: Air-System | Jet System | Combi-System E
⤷ Number of Jets
: 6 | 12 | 24
⤷ Waste Included
: Sold Separately
⤷ Barcode
: 4067116074253

Additional Info & Downloads

Download the Customer Datasheet Pdf File Download the Installation Instructions Pdf File

Technical Images

Duravit Qatego 1800 x 800mm Double Ended Built In Acrylic Whirlpool Bath

Total: £2190.00 3-4 Weeks Approx QS Supplies

2 Features Included In This Product Explained

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.

Jet-System

Jet systems can provide relaxing sensations while you’re in the bath, and you can direct them for a massage-like experience. They raise the airflow’s velocity, providing more pressure from the bubbles, and since we most likely bathe using hot or warm water, the percussive action of the air system’s bubbles gives the muscles a relaxing and soothing experience.
