Duravit Qatego Single Ended Built In Sanitary Acrylic Bath

Duravit Qatego 700609000000000 Details

Key Features

✔Single-ended bath
✔Shape: Rectangular
✔Type of installation: Built in
✔Constructed using sanitary acrylic
✔Designed by Studio F. A. Porsche

Available in 5 different sizes - [Optional].
One backrest slope for complete submerging in water.
Depth: Internal 460mm (46cm) and External 480mm (48cm).
It comes in a White Alpin finish.
Water level capacity - 365mm.
Water Capacity of Bath.
1500 x 750mm Bath - 215 Litres.
1600 x 700mm Bath - 225 Litres.
1700 x 700mm Bath - 240 Litres.
1700 x 750mm Bath - 250 Litres.
1800 x 800mm Bath - 300 Litres.
Download Customer Data Sheet and Installation Instruction PDF from the Additional Info section.

Refer to technical drawing for more technical specifications.
Five-year warranty from Duravit against manufacturing defects.
The waste shown in the image is not included.
Available optional product.
Bathtub Anchor.
Rubber profile.
Support Frame.
Styrene Support for Bath.
Quadroval waste and overflow.
Quadroval waste and overflow with water inlet.
Quadroval waste and overflow with base inlet (for 1800mm bath only).
Noise reduction gasket.

Please Note: Noise reduction gasket #791368 can not be combined with Bathtub support. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in mm and are non-binding. Exact measurements, in particular for customised installation scenarios, can only be taken from the finished ceramic piece.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Qatego
⤷ Interior Shape
: Rounded Rectangular
⤷ Bath Type
: Single Ended
⤷ Position of Drain
: Waste at foot End
⤷ Coating
: Standard
⤷ External Length
: 1500
⤷ External Width
: 750
⤷ Tub Depth
: Internal: 460 | External: 480
⤷ Colour
: White Alpim
⤷ Internal Bottom Length
: 977
⤷ Internal Bottom Width
: 337
⤷ Internal Top Length
: 1400
⤷ Internal Top Width
: 620
⤷ Height of Rim
: 25

⤷ Distance Tub edge to centre of drain hole
: 303
⤷ Distance Top edge to centre of overflow hole
: 97
⤷ Diameter of Drain hole
: 52
⤷ Rim Width
: 65 | 50
⤷ Weight in kg
: 21
⤷ Shape
: Rectangular
⤷ Capacity in litres
: 215
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Acrylic
⤷ No. of Bathers
: 1
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Barcode
: 4067116068870

Additional Info & Downloads

Download the Customer Datasheet Pdf File Download the Installation Instructions Pdf File

Technical Images

Duravit Qatego Single Ended Built In Sanitary Acrylic Bath

Customise Your Product

Anchors

For mounting and support of tubs! Please note: The image shown is for illustration purposes only.

No Option Selected
OP-38868 - Bath Tub Anchors For Mounting And Support + £37.08

Rubber Profile

A high quality product to add extra safety features to your bath! Please note the Image for illustration purposes only.

No Option Selected
OP-108388 - Rubber Profile 3300mm + £22.50

Total: £333.84 3-4 Weeks Approx QS Supplies

1 Features Included In This Product Explained

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.
