QS Basics Amelia Chrome Basin Mixer Tap With Click Waste

OFFL3 Details

QS Basics Amelia Chrome Basin Mixer Tap With Click Waste.

The manufacturing code of this product is OFFL3.
Single lever tap with curved spout.
Deck mounted installation.
Size [mm]: 52mm x 133mm x 137mm [Width x Depth x Height].
Size [cm]: 5.2cm x 13.3cm x 13.7cm [Width x Depth x Height].
Centre of the inlet to centre of outlet: 107mm (10.7cm).
Base to spout: 65mm (6.5cm).

1/2 inch BSP flexi hoses.
Requires minimum 0.2 bar and maximum 1.0 bar operating water pressure.
Suitable for low water pressure system.
Supplied with click waste.
Standards: BS EN 200.
Refer to technical image for additional dimensional details.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Amelia
⤷ Water Activation
: By Lifting/Tilting
⤷ Tap Body Shape
: Square
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: Lifetime
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Ceramic Disc

⤷ Base To Spout
: 65
⤷ Spout Reach
: 107
⤷ Overall Height
: 137
⤷ Width
: 52
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Waste Type
: Click
⤷ Flow Rates (l/min)
: 0.2 Bar - 3.8 / 0.5 Bar - 6.2 / 1.0 Bar - 8.8 / 2 Bar - 12.5 / 3 Bar 15.4
⤷ Handle Style
: Lever
⤷ Waste Included
: Yes
⤷ Compliance/Approvals/Standard
: BS EN 200
⤷ Barcode
: 5060168228437
⤷ Product Type
: Waterfall Basin Tap

Total: £31.68 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Click-Clack Waste

Also called the Push button or Sprung waste, this waste needs a push down on the stopper to close and a click to open it back again. It is the most commonly used waste due to the ease of its operation.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Waterfall Effect

Flow created by the open spout tap is similar to a waterfall and can be created under high water pressure. Water flowing out from the open spout in this cascading effect replicates the same relaxed feeling of a spa.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...
