Nuie Otley Straight Single Ended Acrylic Bath, 1675 x 700mm, NBA308

Nuie introduces the Otley Round Straight Single-Ended Acrylic Bath that will take your bathing pleasures to the next level and reflect your elite taste. This single-ended tub is equipped with generous soaking capacity providing a complete hydro-massage experience through prolonged soaking. Dip your entire body and roll your shoulders even as it has an abundant area.

Lighter materials these days are more in vogue, but the strength of a unit remains essential. Such as this sanitary acrylic bath which comes with a leg set and a 5-years guarantee from the manufacturer against any manufacturing defects. Make the most of the bath by adding a bath panel or bath screen.

The Manufacturing Code of this Product is NBA308
Size [mm]: 1675 x 700 x 370mm [Length x Width x Depth]
Size [cm]: 167.5 x 70 x 37cm [Length x Width x Depth]
Round Single-Ended Bath
It Comes in a White Finish
Overall Height: 390mm (39cm)
Water Capacity: 160 Litre
Displaced Capacity: 90 Litre
Weight: 17 Kg
Suitable for Use with Bath Screen
End Panel Available [Optional]
Bath Waste [Optional]
Download the Customer Data Sheet PDF File from the Additional Info Section
Refer to the Technical Drawing for More Details
Bath Waste and Overflow Shown in the Image are not Included

Info / Size (mm)

Bath
Length: 1675 mm
Width: 700 mm
Depth: 370 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Otley
⤷ Interior Shape
: Round
⤷ Bath Type
: Single Ended
⤷ Position of Drain
: Waste at Foot End
⤷ Coating
: Without Coating
⤷ External Length
: 1675
⤷ External Width
: 700
⤷ Tub Depth
: 370
⤷ Feets Included
: Yes
⤷ Height Including Feet or Panel
: 390
⤷ Front Panel Included
: Sold Separately
⤷ End Panel Included
: Sold Separately
⤷ Colour
: White
⤷ Height of Rim
: 35

⤷ Distance Tub edge to centre of drain hole
: 285
⤷ Distance Top edge to centre of overflow hole
: 350
⤷ Diameter of overflow hole
: 52
⤷ Rim Width
: 50 | 75 | 90
⤷ Weight in kg
: 17
⤷ Shape
: Round
⤷ Capacity in litres
: 160
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Acrylic
⤷ No. of Bathers
: 1
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Tap Holes
: 0
⤷ Barcode
: 5056462696256

1 Features Included In This Product Explained

Optional: End Panel

End Panels serve an aesthetic purpose to cap-off the exposed end of a bathtub and come in different sizes, shapes, designs, and finishes.

Reviews & Ratings

By: James From : Chipping Norton Overall Rating: Date: September 23, 2026 Very satisfied customer

I will definitely use QS Supplies again, great price and top quality product perfect for a recent refurbishment, delivery was actually 5 hours before the given delivery slot, which meant no waiting for it to arrive. Thank you.

Images Uploaded by the users:
