Bristan Dune Chrome Kitchen Sink Mixer Tap

Dune DU SNK C Details

Great design and affordable pricing – that is what this Kitchen Mixer Tap from Bristans Dune range offers you. The deck-mounted model, supplied without waste, is compatible with high and low-pressure systems. It has a swivel spout featuring dual control and is attractive, and it is plated with a flawless chrome finish. Its your turn to get impressed with this solid brass tap which includes 1/4-turn ceramic disc valves for drip-free use. What we like about this tap is that it comes with flexible tails and fixing, kit-making life simple—also, there is no need to go elsewhere when you need hot water. The tap gives you hot water up to 60°C-pure genius!

The manufacturing code of this product is DU SNK C.
It comes in a chrome finish.
Suitable for deck-mounted installation.
Connection Inlet: 1/2 Inch BSP Flexible Tails.
Height: 361mm - (36.1cm).
Depth: 230mm - (23cm).
Spout Reach: 194mm - (19.4cm).
Base To Spout: 232mm - (23.2cm).
Connection Outlet: M24 Flow Straightener.
Valve/Cartridge Type: 1/2 Inch Ceramic Disc Valve - 1/4 turn.

Suitable for all plumbing systems.
Maximum Hot Water Temperature °C: 60°C.
Maximum Static Pressure (bar): 10 bar.
Flow Type: Single Flow.
Flow Rates (l/min): 10.7 Litre/Min @ 0.5 bar.
Suitable for high and low-pressure water systems.
Requires a minimum of 0.5 bar to a maximum of 5.0 bar water pressure system.
Download the Installation Instruction PDF File From The Additional Info Section.
Refer to the technical diagram for the complete technical dimension.

Info / Size (mm)

Taps
Pipe Center: 194 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Range
: Dune
⤷ Handle Position
: Left & Right
⤷ Tap Body Shape
: Round
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck-Mounted
⤷ No. of Holes Required
: 1
⤷ Valve/Cartridge Type
: 1/2 Inch Ceramic Disc Valve - 1/4 turn

⤷ Spout Swivel
: Yes
⤷ Base To Spout
: 232
⤷ Spout Reach
: 194
⤷ Overall Height
: 361
⤷ Inlet Connections
: 1/2 Inch BSP Flexible Tails
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Flow Rates (l/min)
: 10.7 Litre/Min @0.5bar
⤷ Handle Style
: Stick Handle
⤷ WRAS Approved
: Yes
⤷ Barcode
: 5014868070322
⤷ Product Type
: Kitchen Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £45.84 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Luminance Chrome

It is a hard-wearing chrome plating which is salt-tested and scratch-proof for durable, long-lasting use.

Precise Glide

It comes incorporated with ceramic cartridges for long life with precise control for smooth, leak-free use.

Secure Fix

The design features metal fixings that secure your tap, preventing any movement or rotation during use.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

Questions & Answers

Submit Your Questions 2 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Ian Asked :
Hello, I'm looking at buying the Bristan Dune kitchen mixer tap. Can it be installed in the hole in the sink, or is this tap just to be mounted on a worktop?

Answered By QS Team

We can confirm that this tap does need to be installed in a hole (sink or worktop) and then gets secured underneath. Please see the fitting instructions attached for more information.

Was this answer helpful?

David Asked :
Is the dune mixer tap easy-fit, and are all the easy-fit taps interchangeable?

Answered By QS Team

The Dune Kitchen Sink Mixer (DU SNK C) is not from the Bristan Easyfit range. For future reference, the Easyfit taps are interchangeable with the Easyfit base.

Was this answer helpful?
