Tivolis Lugo 600mm High Double Panel Horizontal Aluminium Radiator


RRP: £441.60

Delivery In:

4 Working Days Approx.

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Product Variants
Select Width Step 1
Select Finish Step 2
SKU Code: QS-V98302

MFC Code: 701-600465

Tivolis Lugo 701-600465 Details

Tivolis Lugo 600mm High Double Panel Horizontal Aluminium Radiator is available for purchase in several variations to choose from and comes in a fashionable white or anthracite finish that fits in beautifully to any modern or traditional room layout, anywhere. Designed for horizontal installation, this Double Panel Radiator boasts a light and seamless panel design compatible with your homes central heating system. Though the valves shown in the accompanying image are not included with this product, they can be purchased separately if desired.

Key Features
  • Constructed using aluminium
  • Available in Anthracite and White finish - [Optional]
  • Five-year guarantee from the manufacturer against manufacturing defects
  • All Radiators from Tivolis have been manufactured and tested in accordance with EN442
  • Available in different Width - 512mm, 718mm, 924mm, 1130mm and 1336mm [Optional].
  • Height: 600mm (60cm).
  • Double Panel Radiator.
  • Suitable for horizontal installation.
  • Wall to pipe centres: 74mm (7.4cm).
  • Distance from wall: 109mm (10.9cm).
  • Installation type: Wall mounted.
  • Suitable for central heating systems only.
  • The radiator Valve shown in the image is not included - Sold Separately [Optional].
  • For BTU, Watts and Pipe centres, Please refer PRODUCT VARIATIONS INFO & MFC CODE tab below.
  • All Fittings are supplied with the product with a simple instruction manual.
  • All Radiators from Tivolis are securely packed and protected with a Bubble Wrap.
  • Pipe centres are illustrative and the same with width; please add/subtract up to 90mm considering valve type for measurement.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Lugo
  • ⤷ Colour
  • : White
  • ⤷ Shape
  • : Straight
  • ⤷ Country of Origin
  • : Turkey
  • ⤷ Warranty/Guarantee
  • : 5 Years
  • ⤷ Material
  • : Aluminium
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Width
  • : 512
  • ⤷ Height
  • : 600
  • ⤷ Orientation
  • : Horizontal
  • ⤷ Compliance/Approvals/Standard
  • : EN442
  • ⤷ Barcode
  • : 5057199957092
  • ⤷ BTU Output
  • : 50°C - 1990 | 60°C - 2521
  • ⤷ Watts
  • : 50°C - 583 | 60°C - 739
  • ⤷ Tapping / Pipe Centres
  • : 512
  • ⤷ Valves Included
  • : Sold Separately
  • ⤷ Fuel Type
  • : Central Heating
  • ⤷ Wall to Centre of Inlet
  • : 109
  • ⤷ Panel Configuration
  • : Double

Customise Your Product

Radiator Valves
Radiator Valves

Listed below are the compatible valves that works well with Tivolis towel rail and radiator. It is available in Angled, Straight and Corner version in Sphere, Square and TMV Modal. Please Note: Images shown are for illustration purpose only.

Total: £275.51 4 Working Days Approx QS Supplies
Other Sizes / Finishes
Sizes Available
Other Sizes / Finishes / Variations Available.
QS Code Finish Size / Difference MFC Code
QS-V98301 - Single Panel 701-600466

Product Variations Info & MFC Code
Details Of Radiators
Height Width Pipe Centres BTU @ Delta T50C Watts @Delta T50C BTU @ Delta T60C Watts @Delta T60C Anthracite MFC White MFC
600mm 512mm 512mm 1990 583 2521 739 701-600016 701-600465
600mm 718mm 718mm 2680 785 3396 995 701-600018 701-600461
600mm 924mm 924mm 3568 1046 4521 1325 701-600020 701-600459
600mm 1130mm 1130mm 4891 1433 6197 1816 701-600022 701-600463
600mm 1336mm 1336mm 5162 1513 6540 1917 701-600024 701-600467

3 Features Included In This Product Explained

Optional: Radiator Valve

Optional: Radiator Valve

Radiator valves help control how much hot water enters and leave it, and the flow of water controls how much heat the radiator generates. These are usually found at the radiator's bottom left, and right corners, where the water pipes enter and exit, or can also be present at the bottom near the centre.

Central Heating

Central Heating

'Standard' radiators and towel warmers are connected to your central heating system, so hot water flows through them to heat them.

Double Panel Radiators

Double Panel Radiators

Also known as type 22 radiators, these double panel radiators are constructed using two steel panels and two convectors or sets of fins which emit greater heat output. Its heat output is more than a single panel and will heat up the room much faster. This kind is ideal for larger than average spaces.
