HIGHLIGHTS 1
  • Size: Width 1200mm x Height 2100mm
  • Manufactured from 10mm toughened safety glass
  • Mershield Stayclear easy clean protected glass
  • Left hand door
  • Right Hand Door Optional [See Option]
  • Luxurious mirror glass exterior, transparent smoked glass on the interior
  • Comes with eyelet handle with chrome eyelet and circular filler plate option
  • Extra smooth roller action for quite closing - a quiet glide wheel which softly opens and closes with minimum effort
  • Suitable for recess installation or use with optional side panels
  • Mirror fixed panel size: 610mm
  • Adjustment: 1150 - 1185mm [minimum - maximum]
  • Adjustment with Side Panel: Tray Finish: 1165 - 1190mm [minimum - maximum], Wetroom: 1145 - 1170mm [minimum - maximum]
  • Adjustable door opening size: 505 - 400mm [maximum - minimum]
  • 35mm adjustment (maximum of 12mm adjustment in wall profile on closing side for out of true walls - i.e. on right hand side of image shown)
  • Adjustable wall profiles to compensate for out-of-true walls and have micro adjustment features for fine tuning to obtain a perfect fit and operating action
  • Power shower suitable
  • Wetroom compatible
  • Fully concealed fittings
  • Manufactured in accordance with ISO 9002 and EN 14428 and utilise toughened safety glass to EN 12150
  • Supplied complete with full installation instructions and the necessary fixings
  • Tray and brassware shown in the image are not included
  • Manufacturing code of this product is M108241MHL
  • Lifetime guarantee from the manufacturer [excludes the Mirror coating which has a 5 year guarantee]
  • For installation instructions download PDF from technical tab
  • Side Panel and Tray [See Option]
  • Panel Kit, Extension Profile and Enclosure Wiper [See Option].
TECHNICAL

Please Note all the measurements are in 'mm'
Handed Type Left Hand
Warranty/Guarantee Lifetime
Installation Type Alcove Or With Side Panel
Waste Included Sold Separately
Width 1200
Configuration Door Only
Height 2100
Fixings included Yes
Compliance/Approvals/Standard EN 14428, EN 12150
Door Type Sliding
Glass Type Mirror, Clear
Glass Thickness 10
Number Of Doors 1
Side Panel Included Sold Separately
Profile Adjustment 35
Door Adjustment 1150-1185
Entry Width 505-400
Tray Included Sold Separately
Easy to Clean Glass Yes
Concealed Fixings Yes
Power Shower Proof Yes
Handle Included Yes
Wetroom Compatible Yes

Mershield Stayclear acts as a protective coating which when applied to glass, helps the glass to remain shiny and new without the need for tiresome cleaning. When cleaned correctly it helps prevent the build up of limescale and soap deposits making the shower glass "Easy to Clean".
Please Note: A left hand (L) mirrored side panel must accompany a right handed sliding door and a right hand mirrored side panel (R) must accompany a left handed sliding door.

Merlyn 10 Series 1200mm Mirror Sliding Shower Door

QS-V30942 MFC CODE: M108241MHL

  • Door
  • Width: 1200
  • Height: 2100

£1068.18

RRP: £1643.35 You Save £575.17 on RRP

STOCK AVAILABILITY

5 Working Days Approx

Shipping: FREE


QTY

Statuesque and aesthetically appealing, Merlyn 10 Series Mirror Sliding Shower Door exudes immense luxury. Crafted from toughened safety glass, it is coated with Mershield Stayclear easy clean protection. It has a gorgeous mirrored exterior and a transparent smoked glass internal surface. Designed for left-hand use and optionally available in a right-hand model it comes with eyelet handle. To add to its luxurious feel, it comes with extra smooth roller action for the quietest closing with a glide wheel to reduce effort. It is wet-room compatible and power shower suitable. It comes with concealed fittings and includes adjustments for a perfect fit.

+  Read what's included.. & options available


Left Or Right Hand Option
Left Or Right Hand Option

10 Series Side Panel Options
Series 10 Side Panels

Extra 20mm Extension Profile
Extension Profile

MStone Shower Tray
Shower Tray

Panel Kit With Legs For Merlyn Tray
Shower Tray Panel Kit

Enclosure Wiper
Merlyn Shower Wiper

OTHER SIZES / FINISHES
Sizes Available
Other Sizes / Finishes / Variations Available.
QS Code Finish Size / Difference MFC Code
QS-V39076 - Width 1400mm M108291MHL
