Geberit VariForm Oval Undercounter Washbasin White

Geberit VariForm 500.748.01.2 Details

The Geberit VariForm Oval Undercounter Washbasin is a uniquely shaped, classically crafted unit that is constructed from strong and sturdy vitreous china material and offered in a striking, bright white finish. Suitable for mounting in a wash top and complete with the fastening material required for installation, this product does not include the connector clou, waste or bottle trap required, though they are available separately for purchase. This unit is available in several sizes and can be used to add stylish functionality to any space.

Basin with or without overflow available [Optional].
Available sizes Width 480mm x Depth 390mm and Width 560 x Depth 460mm [Optional].
Height: 181mm (18.1cm).
It comes in a white finish.
Shape: oval.
Suitable for mounting in wash tops.

Fastening material included.
Connector clou for washbasins without overflow [Optional].
Waste for washbasins with/without overflow [Optional].
Bottle trap for washbasins [Optional].
Refer to the technical drawing for more technical specifications.
Download the Installation Manual PDF File from the Additional Info Section.

Info / Size (mm)

Basin
Width: 480 mm
Depth: 390 mm
Height: 181 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Variform
⤷ Coating
: Without Coating
⤷ Colour
: White
⤷ Shape
: Oval
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Projection (Depth)
: 390

⤷ Width
: 480
⤷ Height
: 181
⤷ Distance between centre holes
: 120
⤷ Inner Bowl Width
: 420
⤷ Inner Bowl Depth
: 330
⤷ Distance rear edge to centre of waste hole
: 195
⤷ Number of bowls
: 1
⤷ Overflow Included
: Yes
⤷ Barcode
: 4025416770909
⤷ Product Type
: Inset Basin

Additional Info & Downloads

Download the Installation Manual Pdf File

Customise Your Product

Washbasin connector clou

Please Note: The image shown For washbasins without visible overflow is for illustration purposes only.

None
OP-142649 - Washbasin Connector Clou With Lever Actuation + £94.64
OP-142650 - Washbasin Connector Clou With Cable Actuation And Turn Handle + £216.42

Bottle Trap

Please Note: The image For washbasins is shown for illustration purposes only.

None
OP-142661 - Bottle Trap - Horizontal Outlet Plastic + £32.21

Waste

Select the appropriate waste from the list below. Please Note: The image shown is for illustration purposes only.

None
OP-142651 - Waste Chrome With Freeflow Waste Cover - 50mm Length + £92.04
OP-142654 - Waste Chrome With Freeflow Waste Cover - 80mm Length + £92.04

Total: £118.67 5 Working Days Approx QS Supplies

2 Features Included In This Product Explained

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.

Fireclay

It is incredibly hard-wearing and has an everlasting shiny surface. They have a high heat resistance (1600°C) and are chemical resistant, non-porous, and hygienic.
