Nuie Hardy Chrome Bath Shower Mixer Tap - Angled Lever Handles

Nuie Hardy Details

MFC: HDY303

The Nuie Hardy Bath Mixer Tap Chrome is suitable for installation within any modern bathroom design and comes in a luxury chrome finish. Manufactured from strong, high-quality brass material and designed for deck-mounted installation, this product also includes quarter-turn ceramic disc technology that provides smooth movement and operation. Suitable for use within a low-pressure water system, this unit requires a minimum of only 0.1 bar for proper functionality.

Key Features

✔Available in Multiple Variants [Optional]
✔It comes in a Chrome Finish
✔Manufactured using High-Quality Brass Material
✔Ceramic Disc Technology for Long Life and Smooth Operation
✔Cartridge Type: 1/4-Turn Ceramic Disc
✔5-Year Guarantee from Hudson Reed against any Manufacturing Defects

Squared-off Edges and Clean Lines Give any Bath a New and Updated Look
Pipe Size: 22mm (3/4-Inch BSP)
Size: Width 230 x Depth 175 x Height: 151mm
Centre of Inlet to Centre of Outlet: 136mm
Inlet Centre: 180mm
Base to Spout: 105mm
Refer to the Technical Drawing for Size Details
Please Refer to the Customer Data Sheet and Fitting Instructions PDF Files from the Additional Info Section Below
Specifications For Without Kit:
Size: Width 230 x Depth 175 x Height: 151mm
Manufactured using High-Quality Brass Material
Weight: 2.39kg
Suitable for Low Water Pressure System
Required Minimum 0.1 Bar or Above Water Pressure
Flow Rates: (Litres Per min) 0.1 Bar: 4.9, 0.5 Bar: 11.8, 1 Bar: 17.1, 2 Bar: 24.2, 3 Bar: 29.8
Specifications For With Shower Kit:
Handset, Hose and Wall Bracket Included
Manufactured using High-Quality Brass and ABS Material
Tap Spout Projection: 136mm
Size: Width 230 x Depth 151 x Height: 151mm
Weight: 2.93kg
Inlet Connection: G1/2-Inch
Suitable for Low Water Pressure System
Required Minimum 0.2 Bar or Above Water Pressure
Flow Rates: (Litres Per min) 0.1 Bar: 5.7, 0.5 Bar: 13.4, 1 Bar: 19.4, 2 Bar: 27.5, 3 Bar: 34

Info / Size (mm)

Tap
Pipe Center: 136 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Material
: Brass
⤷ Spout type
: Fixed
⤷ Base To Spout
: 105
⤷ Overall Height
: 151

⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Flow Rates (l/min)
: 0.1 bar: 4.9 | 0.5 bar: 11.8 | 1 bar: 17.1 | 2 bar: 24.2 | 3 bar: 29.8
⤷ Handle Style
: Lever

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Fitting Instructions Pdf File

Nuie Hardy Deck Mounted Chrome Bath Shower Mixer Tap - Angled Lever Handles

£103.60

RRP: ~~£219.00~~

IN-STOCK

Delivery in 4 Working Days Approx.

QS Supplies

2 Features Included In This Product Explained

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...
