Bayswater Dual Thermostatic Chrome Concealed Shower Mixer Valve

Bayswater Dual BAYS192 Details

The Bayswater Dual Thermostatic Concealed Shower Valve is a TMV2 and WRAS approved a product that comes with a stunning chrome finish that stands out in your shower. Suitable for surface, recessed as well as wall installation, this unit is constructed using amazingly strong and durable brass material, so it will keep looking and working its best for a long time to come. Requiring a minimum of 0.1 bar of water pressure, it is great for use in even low-pressure systems. With a dazzling chrome finish, this product is a simply stylish way to bring water into your shower.

It comes in a chrome finish.
Cartridge type: 1/4 turn.
Requires a minimum 0.1 bar water pressure system.
Flow rate at: 0.1 bar - 5.5 Ltr, 0.5 bar - 14.5 Ltr, 1 bar - 22 Ltr, 2 bar - 30 Ltr, 3 bar - 35 Ltr.
Pipe size: 15mm (1/2inch BSP).

Weight: 3.44 kg.
The manufacturing code is BAYS192.
Diameter: Ø185mm [18.5cm].
Pipe centres: 155mm [15.5cm].
Suitable for wall installation.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 20 Years
⤷ Material
: Brass
⤷ Theme
: Traditional
⤷ Installation Type
: Wall Mounted
⤷ Inlet Centres
: 150
⤷ Overall Height
: 166
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Flow Rates (l/min)
: 0.1 bar - 5.5, 0.5 bar - 14.5, 1 bar - 22, 2 bar - 30, 3 bar - 35
⤷ WRAS Approved
: Yes

⤷ Depth
: 153
⤷ Temperature Control
: Thermostatic
⤷ TMV2 Approved
: Yes
⤷ Number of Handles
: 2
⤷ Plumbing Option
: Exposed
⤷ Overall Width
: 196
⤷ Maximum Operating Pressure (Bar)
: 4
⤷ Cartridge Included
: Yes
⤷ Cartridge Type
: 1/4 Turn

Total: £281.38 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

TMV2 Approved Product

TMV2 is an independent certification for thermostatic mixers, including shower valves, run by BuildCert that ensures national and international standards as specified under (BS EN 1111 and 1287) are met. These standards detail the exacting requirements that a thermostatic valve or product must comply with to guarantee a high thermostatic protection and safety standard. Products meeting this requirement carries the logo and protect against any scalding accidents.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

Bar Pressure

Bar is a unit of pressure, which is accepted for use with SI by The International Bureau of Weights and Measures. The bar is used as it is almost equal in value as the standard atmosphere which is 1.01325 bar.
