Geberit Type10 Pneumatic Dual Flush Concealed Actuator

£69.17

RRP: £135.24

Delivery In:

4 Working Days Approx.

Not Yet Rated No Rating

Shipping: £7.95

Product Variants
Select Variant Step 1
Select Finish Step 2
SKU Code: QS-V93579

MFC Code: 116.056.KJ.1

Geberit Type10 116.056.KJ.1 Details

The Geberit Type10 Pneumatic Dual Flush Concealed Actuator is suitable for use with a concealed cistern and comes in 8cm, 12cm, and 15cm size options. Requiring an actuation force of 25N for proper functionality, this product is designed to be combined with a compatible Geberit flush plate for single flush and/or stop-and-go flush systems, or with Geberit cover plate in other installation situations. Available in 5 different finish options to choose from, this model also includes the fixing materials required for secure installation along with it upon purchase.

Key Features
  • Choice of different finish: White Alpine, Gloss Chrome and Matt Chrome
  • Manufactured using plastic material
  • Flush-mounting box with protection cover
  • 1-year guarantee from Geberit against manufacturing defects.
  • WC button type: Single and Dual [Refer Option].
  • Suitable to use with concealed cisterns 8cm, 12cm and 15cm [Refer Option].
  • Size: Ø 94mm (9.4cm).
  • 74 mm (7.4cm) hole required.
  • Round design.
  • Can be combined with Geberit flush plates for single or dual flush and stop-and-go flush or Geberit cover plate.
  • Actuation force: < 25 N.
  • Refer to the technical drawing for more specification.
  • Please download the Installation Instructions PDF from the Additional Info Section.
  • Application purposes For 8cm Cistern.
  • For pneumatic remote flush actuation of Geberit concealed cisterns.
  • For single or dual-flush.
  • For solid and drywall construction.
  • For concealed installation.
  • For Geberit Sigma concealed cisterns 8 cm.
  • Application purposes For 12cm and 15cm Cistern.
  • For pneumatic remote flush actuation of Geberit exposed and concealed cisterns.
  • For single or dual-flush.
  • For solid and drywall construction.
  • For concealed installation.
  • For Geberit Delta, concealed cisterns 12 cm.
  • For Geberit Sigma, concealed cisterns 12 cm.
  • For Geberit Omega concealed cisterns 12 cm.
  • For Geberit Kappa, concealed cisterns 15 cm.
  • Scope of delivery.
  • Actuator.
  • Pneumatic flushing device.
  • Pneumatic hose length: 2 m.
  • Conduit pipe length: 1.7 m.
  • Fastening material.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : White Gloss and Chrome
  • ⤷ Shape
  • : Round
  • ⤷ Country of Origin
  • : Germany
  • ⤷ Material
  • : Plastic
  • ⤷ Flush Type
  • : Dual Flush
  • ⤷ Operation Type
  • : Pneumatic
  • ⤷ Actuation force
  • : < 25 Newton
  • ⤷ Compatible With
  • : Concealed Cisterns

Additional Info & Downloads

Download PDF Download the Installation Instruction Pdf File


Technical Images


Total: £69.17 4 Working Days Approx QS Supplies

2 Features Included In This Product Explained

Dual-Flush

Dual-Flush

A toilet with a flushing mechanism with two different buttons for flushing solid and liquid waste, thereby saving water.

Drywall

Drywall

Drywall, or wallboard, also called plasterboard or gypsum board, is a common building material used in interiors for constructing walls and ceilings. Drywall is gypsum plaster in the middle with layers of paper or fiberglass mats on either side. Drywalls do not need mortar or plaster. The gypsum core is rigid, and the other surface is smooth.

You've Selected which adds to a total of

Reviews & Ratings

Rate this Item.:

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Darren Asked :

Will this work with any dual flush, concealed cistern - we have previously purchased a Twyford dual flush cistern.

Answered By QS Team Answered by the QS Technical Team

The Geberit button is supplied to fit any of the Geberit cisterns only, and they will not work on the Twyford range of cisterns.
