Dq Heating Ashill Traditional Wall Mounted Towel Radiator

DQ Ashill ASHILL-1W-CP Details

DQ Heating brings you the astounding Ashill Traditional Wall Mounted Heated Towel Rail, which is compact, highly effective and suitable for central heating systems. It makes an impression with meticulously handcrafted brass construction with mild steel inserts in an excellent choice of colour options. For a luxurious look, the Luxury handmade traditional design can be purchased in Chrome, Polished Brass, Polished Nickel, Brushed Nickel, Antique Brass, or Polished Gold. Easy to fit and maintain a dual-fuel version of the bathroom radiator is also available optionally.

Key Features

✔Constructed from brass with mild steel radiator inserts
✔Luxury handmade traditional design
✔Suitable for central heating systems
✔Five years of guarantee against any manufacturing defects

Available in 6 finishes.
Available Width: 500mm, 685mm, 837mm.
Size In [mm]: 505mm x 200mm [Height x Depth].
Size In [cm]: 50.5cm x 20cm [Height x Depth].
Wall-to-inlet distance: 50mm - (5cm).
Connections: 1/2 Inch flow and returns.
Tested pressure: 7 Bar.

Testing authority: EN442.
Max operation pressure: 4 Bar.
Max working temperature: 95ºC.
BTU at 50ºC: 1171 (500mm Width), 1787 (685mm Width), 2199 (837mm Width).
Valves shown in the image are not included and are sold separately.
Valves are available separately Click Here.
Refer to the technical diagram for complete technical dimensions.

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Ashill
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Installation Type
: Wall Mounted
⤷ Projection (Depth)
: 200
⤷ Width
: 500
⤷ Height
: 505

⤷ Orientation
: Horizontal
⤷ Barcode
: 5057199075451
⤷ BTU Output
: 1171
⤷ Watts
: 343
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating
⤷ Tube Diameter
: 31.8
⤷ Pressure Tested (bars)
: 7

Additional Info & Downloads

Download the Installation Instructions Pdf File

Technical Images

Dq Heating Ashill Traditional Wall Mounted 505mm High Heated Towel Rail

Total: £921.61 Special Order Enquire for Delivery date QS Supplies

2 Features Included In This Product Explained

Mild Steel

Mild Steel is the most common radiator material. It is inexpensive, available in a variety of designs and finishes, lightweight and durable.

Central Heating

'Standard' radiators and towel warmers are connected to your central heating system, so hot water flows through them to heat them.
Read more...

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Chantal Asked :
Hi, we have self-built and are speccing the final fit-out, completing things as income allows. We are looking at dual fuel towel radiators, as we have solar. And I would like to know which are the lower-priced traditional types that will allow me to make the dual-fuel conversion. Must they have a base inlet/outlet in order to make the conversion? I've been googling for hours and can't get an answer on the inlet position, as I can see that the element must align with a straight internal pipe in order to convert to electricity. Many thanks for your help. I will be buying 5 of these, so I need to choose a good-priced one and be sure that I've covered off this question.

Answered By QS Team

We can confirm that all DQ essential traditional towel rails can be converted to dual fuel. The element is fitted independently from the valves meaning that there is no need for a tee piece to be used.
