Hudson Reed Salvia Double Panel Vertical Designer Radiator

Hudson Reed Salvia HSA002 Details

The Hudson Reed Salvia White Double Panel Designer Radiator is suitable for Vertical installation and puts out an exceptional amount of heat at several different wattage levels. Constructed from solid and long-lasting steel material, it will perform flawlessly for years to come.

A unit that comes complete with brackets for solid installation, this product functions to provide welcoming heat in style. Available in two sizes and two finishes of White and Anthracite, this radiator fits in perfectly with modern and traditional decor. Compatible radiator valves can be purchased optionally from our online store.

Key Features

✔Material: Steel
✔Exceptional heat output
✔Brackets included
✔Five years of guarantee from Hudson Reed

Available in different heights: 1500mm and 1800mm - [Optional].
Choice of different finishes available: White and Anthracite [Optional].
Size [mm]: 383mm x 80mm [Width x Depth].
Size [cm]: 38.3cm x 8cm [Width x Depth].
Installation type: Wall Mount/Vertical.
It comes complete with fixing screws.
All tappings are 1/2 inch BSP.
Pipe centres: 473mm (47.3cm).
Wall to Centre of Tapping: 80mm (8cm).

No of heat setting: 1.
Number of Sections / Panel: 12.
The maximum projection from the wall: 1500mm (150cm) - 130mm (13cm) and 1800mm (180cm) - 190mm (19cm).
Valves shown in the image are not included - sold separately.
Suitable valve available in Compatible Valves tab below [Optional].
Towel rail and Robe hook [Optional].
Refer technical drawing for complete size details.
Download Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section.

Note: It is recommends that the pipework should not be done until the heated towel rail is receipt. After installing any new radiators, when refilling the system, it is recommended that a suitable inhibitor is used. Dimensions are subject to minor deviations.

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Salvia
⤷ Colour
: White
⤷ Warranty/Guarantee
: 20 Years
⤷ Material
: Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Width
: 383
⤷ Height
: 1500

⤷ Orientation
: Vertical
⤷ Barcode
: 5057199444615
⤷ BTU Output
: 30°C - 1666 | 50°C - 3105 | 60°C - 3879
⤷ Watts
: 30°C - 488 | 50°C - 910 | 60°C - 1137
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating
⤷ Panel Configuration
: Double

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instruction Pdf File

Technical Images

Hudson Reed Salvia 383mm Wide Double Panel Vertical Designer Radiator

Customise Your Product

Radiator Accessories

Hudson Reed provides strong and durable accessories for its radiator. Please Note Image shown is for illustration purpose only.

OP-101782 - Magnetic Robe Hook + £26.06
OP-101783 - Radiator Hook + £17.03
OP-101785 - Robe Hook for Radiator + £11.75
OP-101784 - Magnetic Towel Rail + £60.71
OP-101786 - Towel Rail for Radiator + £41.50

Total: £139.30 3-4 Working Days Approx QS Supplies

Other Sizes / Finishes

Other Sizes / Finishes / Variations Available.

QS Code	Finish	Size / Difference	MFC Code
QS-V94183		Ex-Display	HSA001-EX

Back to QS-V90271 / MFC Code: HSA002

2 Features Included In This Product Explained

RAL Colours

It refers to a European colour-matching system which defines colours for coatings, paints, and plastics. The colour standard is administrated by the RAL Deutsches Institut für Gütesicherung und Kennzeichnung.
Read more...

Double Panel Radiators

Also known as type 22 radiators, these double panel radiators are constructed using two steel panels and two convectors or sets of fins which emit greater heat output. Its heat output is more than a single panel and will heat up the room much faster. This kind is ideal for larger than average spaces.
