Vado Elements Stainless Steel Mono Kitchen Sink Mixer Tap

Vado Elements CUC-1063-S/S Details

Vado Elements Steel Mono Kitchen Sink Mixer Tap comes with a delightful curved profile and a swivel spout. A contemporary offering, it is styled from high-quality materials for a durable finish. The kitchen chores will seem a delight with this at the deck of your sink.

It works with a minimum operating pressure of 0.5 bar and is effortlessly functional in medium-pressure systems. Covered with a 15-years guarantee from the manufacturer, it is brought to you at a neat discount price at our online store. This wondrous product will heighten the beauty and practicality quotient of your bathroom.

The manufacturing code of this product is CUC-1063-S/S.
Deck-mounted installation.
Requires minimum 0.5 bar operating pressure.
Suitable for medium water pressure systems.
Base to spout: 305mm (30.5cm.

Height: 404mm (40.4cm).
Cold ceramic cartridge C-207-RTC.
Hot ceramic cartridge C-207-LTC.
Refer to the technical diagram for more technical details.
Download the installation instruction PDF from the Additional Info section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Elements
⤷ Handle Position
: Left & Right
⤷ Tap Body Shape
: Round
⤷ Colour
: Stainless Steel
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Swivel
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Cold Ceramic Catridge/ Hot Ceramic Catridge
⤷ Spout Swivel
: 10-Degree

⤷ Base To Spout
: 305
⤷ Spout Reach
: 184.5
⤷ Overall Height
: 404
⤷ Max. Deck Thickness
: 40
⤷ Inlet Connections
: 2 x G1/2 Inch
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Flow Rates (l/min)
: 3 Bar - 16.6
⤷ Handle Style
: Crosshead
⤷ WRAS Approved
: Yes
⤷ Flow Regulator Included
: Sold Separately
⤷ Barcode
: 5052120167991
⤷ Product Type
: Kitchen Sink Mixer Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £236.26 2 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Swivel-Spout

The respective apparatus is engineered with the ability to move sideways or at certain angles, which helps them cover a greater area than would be possible in a stationary position.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...
