IMEX Arco Chrome Single Outlet Exposed Thermostatic Bar Valve With Slide Rail Kit

IMEX Arco XCSRSP Details

The IMEX Arco Single Outlet Exposed Thermostatic Bar Valve utilises cylindrical forms and smooth curves, and this circular profile makes an ideal inclusion in the interior that embraces soft, contemporary fashion. Separate pressure and temperature valves are located at opposite ends of the mixer for a user-friendly control interface. Featuring a built-in thermostatic function, this unit automatically shuts off the water supply should the cold water feed be interrupted to prevent scalding and ensure a safe, comfortable showering experience. It is accompanied by an adjustable slide rail, a single function air mix handset and flexible hose to complete your shower unit. The fabulous chrome finish lends it a degree of class and sophistication.

Includes thermostatic valve, adjustable slide rail, single-function air mix handset and hose.
The manufacturing code is XCSRSP.
The minimum water pressure recommended for smooth working is 0.2 bar [LP-Low Pressure].
Valve:.
The overall width is 275mm [27.5cm].
The Inlet centre is 150±20mm [15-2cm].
G1/2 inch outlet connection.

Slide Rail Kit:.
Size [mm] - 70mm x 706mm [Projection x Height].
Size [cm] - 7cm x 70.6cm [Projection x Height].
Works with all contemporary plumbing systems and conventional gravity-fed system.
For complete size details, refer to technical drawing.
Download Aftercare Guide PDF File from the Additional Info Section.
Optional Products: Easy Fixing Wall Mounting Kit.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Exposed
⤷ Inlet Centres
: 150±20
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Hose Included
: Yes
⤷ Spray Setting
: 1
⤷ Configuration
: Valve, Slide Rail, Hose And Handset

⤷ Temperature Control
: Thermostatic
⤷ Anti-Scald
: Yes
⤷ Product Type
: Shower Set
⤷ Separate temperature and power controls
: Yes
⤷ Auto shutdown if hot or cold supplies fail
: Yes
⤷ Handset Included
: Yes
⤷ Valve Size
: Width 275mm
⤷ Rail Length
: 706

Additional Info & Downloads

Download the Product Aftercare Guide Pdf File

Total: £95.92 5 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Suitable For Gravity Fed System

You can use a shower, showerhead or tap with a gravity-fed water system with a hot and cold water feed. Usually found in old properties, these typically have low pressure of water flow.

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Emma Asked :
Can I ask how long the hose is? It's mentioned it's flexible, but how does that work?

Answered By QS Team

The hose is 1.5m long and is flexible to allow you to move the shower handset with a full range of movement. The handset can be angled, lowered and raised using the handset holder.
