Nuie Asselby White Basin And Toilet Set

Nuie Asselby CSS004 Details

Defining in looks, and classy in style, this Asselby White 4 Piece Cloakroom Suite from Nuie will impart elegant charm to your bathroom. The superb white finishing of the bathroom sink and comfortable toilet will beautifully complement your bathroom decor. Long-lasting use is assured, as the suite is built from durable high quality ceramic. Nuie provides a 5 year guarantee on this cloakroom suite.

Manufacturing code of this product: CSS004 | NTS007 | CSS002.
It comes in a white finish.
Download Customer Data Sheet PDF File from the Additional Info Section.
Refer technical drawing for more details.
Details For Toilet:.
Include top fix soft close seat with quick release feature.
Overall size [mm]: 410mm x 670mm x 810mm [Width x Projection x Height].
Overall size [cm]: 41cm x 67cm x 81cm [Width x Projection x Height].
The height of the pan: 405mm (40.5cm).

It comes complete with fittings.
Details For Basin:.
Include full pedestal.
Size [mm]: 600mm x 430mm x 817mm [Width x Depth x Height].
Size [cm]: 60cm x 43cm x 81.7cm [Width x Depth x Height].
The height of the pedestal: 660mm (66cm).
Tap and waste shown in the image are not included - sold separately.
Contemporary basin design and full pedestal for a classic look.

Info / Size (mm)

Toilet
Width: 320 mm
Projection: 700 mm
Height: 760 mm

Basin
Width: 600 mm
Depth: 430 mm
Height: 830 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Suite Includes
: Basin | Toilet
Basin Features
⤷ Basin Colour
: White
⤷ Basin Size - (Width x Depth x Height)
: W 600 x D 430 x H 160
⤷ Sink Material
: Vitreous China
⤷ Basin Waste Included
: Sold Separately
⤷ Basin Tap Included
: Sold Separately
⤷ Pedestal Included
: Yes
⤷ Pedestal Type
: Full
⤷ Height With Pedestal
: 660
⤷ Basin Tap Holes
: 1
⤷ Sink Type
: Floor Mounted
⤷ Sink Shape
: Semi Circle
Toilet Features
⤷ WC Colour
: White
⤷ WC Pan Size - (Width x Depth x Height)
: W 370 x H 405
⤷ Toilet Overall Height
: 810

⤷ Toilet Projection (Depth)
: 670
⤷ Cistern Included
: Yes
⤷ Cistern Type
: Close Coupled
⤷ Cistern (Width x Height x Depth)
: W 410 x D 145 x H 370
⤷ Flush Type
: Dual Flush
⤷ Full Flush Volume in litres
: 6
⤷ Half Flush Volume in litres
: 4
⤷ Flush Mechanism
: Push Button
⤷ Cistern Lever Or Button Placement
: Top
⤷ Toilet Material
: Vitreous China
⤷ Seat Included
: Yes
⤷ Seat Type
: Soft Close
⤷ Seat Finish
: White
⤷ Toilet Installation Type
: Floor Mounted
⤷ Warranty/Guarantee
: 5 Years
⤷ Theme
: Modern

Additional Info & Downloads

Download the Customer Data Sheet For WC Pan Pdf File Download the Customer Data Sheet For Seat Pdf File Download the Customer Data Sheet For Basin And Pedestal Pdf File

Total: £222.25 3-4 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Soft-Close Seat

Soft-closing seats are a new alternative to classic toilet seats. Their modern design allows them to close slowly, while their controlled manner of closing does not require you to assist them. It also shuts automatically, allowing it to come down at a pace that does not make much noise.

Dual-Flush

A toilet with a flushing mechanism with two different buttons for flushing solid and liquid waste, thereby saving water.

Quick Release Toilet Seat

The hinge on a regular toilet seat makes it challenging to clean in some areas. As a result, some areas build up with hairs, grime, and dirt over time. Fortunately, the invention of a quick-release toilet seat means you can keep your entire toilet clean. The hinge mechanism of these toilets allows you to remove the seat entirely, making it easier to wash the areas it covers on the toilet itself.

Vitreous-China Material

It is a compound of glass and silica-based materials applied as a coat on porcelain products such as WC pans, urinals, baths and basins to protect them from scratches and stains as an anti-vandal measure.
