VitrA S20 480mm White Wall Hung Short Projection WC Pan

Technical drawing QS-V59722 / 5505L003-0101

£90.00

STOCK AVAILABILITY

2 Working Days Approx

4.3 out of 5

Based on 3 Ratings.

Shipping: £20.00

QTY

Key Features

✔Horizontal connection outlet
✔Made using ceramic material
✔Ten years guarantee from the manufacturer

SKU Code: QS-V59722

MFC Code: 5505L003-0101

+ Review this Product
+ Questions Answered

Vitra S20 5505L003-0101 Details

Where a bathroom demands a compact WC, this S20 Wall-Hung WC by VitrA is the ideal choice for your contemporary style cloakrooms or bathrooms. This WC has a short projection from the wall, thereby requiring less space. The shape of this WC is excellently crafted to go well with the cosy dimensions and pristine white finish.

Manufacturing code: Pan - 5505L003-0101, Toilet seat - 77-003-001.
Size [mm]: 360mm x 400mm [Width x Height].
Size [cm]: 36cm x 40cm [Width x Height].
Projection from wall: 480mm (48cm).
Short projection WC.

It comes in a white finish.
Compatible toilet seat [Optional].
Weight: 17.18 Kg.
The toilet seat shown in the image is not included.
Refer to the technical drawing for more details.

Info / Size (mm)

Toilet
Width: 360 mm
Projection: 480 mm
Height: 400 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: S20
⤷ Toilet Design
: Short Projection
⤷ Colour
: White
⤷ Weight in kg
: 17.18
⤷ Country of Origin
: Turkey
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Ceramic
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Projection (Depth)
: 480
⤷ Width
: 360

⤷ Outlet
: Horizontal
⤷ Configuration
: Bowl Only
⤷ Height
: 400
⤷ Seat Included
: Sold Separately
⤷ Barcode
: 8693405307977
⤷ Distance from floor to centre of fixing hole
: 320
⤷ Bowl Shape
: Square
⤷ Product Type
: Wall Hung WC
⤷ Pan fixing centres
: 180
⤷ Outlet Diameter
: 102
⤷ Base to centre of outlet
: 220

Total: £90.00 2 Working Days Approx QS Supplies

2 Features Included In This Product Explained

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Optional: Soft-Close Seat

Soft-closing seats are a new alternative to classic toilet seats. Their modern design allows them to close slowly, while their controlled manner of closing does not require you to assist them. It also shuts automatically, allowing it to come down at a pace that does not make much noise.

You've Selected which adds to a total of

Reviews & Ratings

Rate this Item.:

Hide All Reviews

By: dominica From : LEWES Overall Rating: Date: December 5, 2016 short depth

I got this because of the short depth, works a treat just squeezed in my bathroom, and the squared look with rounded corners compliments the sink perfectly. However, due to its short depth, the inside design is, how shall I put it? Just in the wrong position for number two! The toilet brush gets a lot of use; maybe I should have paid more and got the Laufen! Well made tho. The toilet seat hinge has been okay. And the scratched item on the first delivery was swiftly replaced.

Helpful?

Quality:

Style

Value for Money

By: James From : Surrey Overall Rating: Date: July 6, 2016 Great slimline hung toilet pan

I selected this model because it extends out 48cm, which is shorter than most. It has fitted perfectly into a small area. It doesn't feel any smaller than other toilets, and suits a tall man like myself. The shape of the bowl also ensures almost all waste drops directly into the water with virtually none clinging to the sides. I highly recommend this.

Helpful?

Quality:

Style

Value for Money

By: Sylvia From : Yateley Overall Rating: Date: July 31, 2015 Bad chrome on seat cover

Toilet was fine, satisfied with that. Problem is chrome cap which hides the bolts that go through the toilet to hold the seat. Have gone rusty so inferior fittings supplied.

Helpful?

Quality:

Style

Value for Money

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Monika Asked :
Hi, VitrA S20 Wall Hung Short Projection WC Pan With Toilet Seat- please advise me which Rama will fit into this toilet ?? I need a height of up to 1000 Thank you

Answered By QS Team

We are not sure what you mean by Rama?

Was this answer helpful?

Vitra S20 Range Of Products
