Hudson Reed Apex Double Door Sliding Offset Quadrant Shower Enclosure

Hudson Reed Apex M9080Q-E8 Details

Looking for an easy-to-fit and easy-to-clean enclosure for your shower? Get the new Hudson Reed Apex Offset Quadrant Shower Enclosure. Its durability comes from toughened safety glass, and this double-door shower quadrant has chrome-plated magnetic door strips that keep it looking new for a long time. The shower shield coating and the smooth gliding doors fitted with quick release bottom rollers make it very easy for you to clean this unit. The manufacturer gives the lifetime guarantee adequately covers manufacturing defects if any.

Key Features

✔Completes double sliding door with minimalist Square T-bar handles
✔Constructed using 8mm (0.8cm) toughened safety glass
✔Smooth gliding doors
✔Chrome magnetic door closing strips, which maintain a shower-proof seal

Available in 4 different sizes: 900mm x 800mm, 1000mm x 800mm, 1200mm x 800mm and 1200mm x 900mm - [Optional].
Available handle variants: Square and Round - [Optional].
Height: 1900mm (190cm).
Radius: 538mm (53.8cm).
Framed design enclosure.
Reversible design - can be fitted on the left or right hand.
Handle material: Metal.
Aluminium profile in polished chrome finish.
Patented Easyfit profile assembly technology as standard.
Supplied with Hidden fixings - chrome finish profile covering fixings for a sleek look.
Quick-release bottom rollers for easy cleaning.
Out of true wall adjustment: 40mm (4cm).

Shower Shield surface coated glass, which repels water and prevents limescale build-up, significantly reduces cleaning time.
Supplied with screw cover strips and fixing.
Suitable for commercial use.
The support bar, Tray and brassware shown in the image are not included.
Compatible shower tray - [Optional].
Easy Plumb Kit for tray - [Optional].
Shower Tray waste - [Optional].
Profile extension kit - [Optional].
Download the Installation Instruction and Customer Data Sheet PDF from the Additional Info section.
Refer to the technical diagram for complete technical dimensions.
Lifetime guarantee from the manufacturer against any manufacturing defects.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Apex
⤷ Handle Finish
: Chrome
⤷ Coating
: Shower Shield Surface
⤷ Weight in kg
: 56.5
⤷ Shape
: Offset Quadrant
⤷ Warranty/Guarantee
: Lifetime
⤷ Installation Type
: Corner
⤷ Radius
: 538
⤷ Handle Style
: T-Bar
⤷ Waste Included
: Sold Separately
⤷ Width
: 880
⤷ Depth
: 780
⤷ Configuration
: Panels And Doors
⤷ Height
: 1900
⤷ Compliance/Approvals/Standard
: CE
⤷ Barcode
: 5055369080540

⤷ Door Type
: Sliding
⤷ Frame Design
: Framed
⤷ Frame / Profile Finish
: Polished Chrome
⤷ Frame Material
: Metal
⤷ Glass Thickness
: 8
⤷ Number Of Doors
: 2
⤷ Profile Adjustment
: 760-780mm And 860-880mm
⤷ Entry Width
: 440
⤷ Closing / Opening Mechanism
: Quick Release Rollers
⤷ Tray Included
: Sold Separately
⤷ Easy to Clean Glass
: Yes
⤷ Concealed Fixings
: Yes
⤷ Handle Included
: Yes
⤷ Profile Cover Caps
: Yes
⤷ Tray Compatible
: Yes
⤷ Door Opening
: Reversible

Additional Info & Downloads

Download the Fitting Instructions Pdf File Download the DataSheet For Offset Quadrant Enclosure Pdf File

Technical Images

Hudson Reed Apex Double Door Sliding Offset Quadrant Shower Enclosure

Total: £299.22 3-4 Working Days Approx QS Supplies

2 Features Included In This Product Explained

Toughened Safety Glass

Toughened glass, tempered or safety glass as it is rightly called, is five times harder than regular glass of the same size and thickness, which makes it so that it won’t break as easily. It also shatters with scattering as it tends to break into tiny, blunt pieces without harming anyone nearby. Known to have greater thermal strength, this durable material with double glazing has almost twice the soundproofing abilities and provides excellent heat insulation.

Reversible Door

A reversible door can be fit to open either to the right or left, depending on the dimensions of your space.

Questions & Answers

Submit Your Questions 3 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Daniyal Asked :
I'm interested in the 800*900 shower. It's gonna go in the right corner, so would I need the left quadrant tray? Also, I need the right-hand length to be 800 going down and 900 at the top going across. Is that the default option, or what do I choose to get this right, please?

Answered By QS Team

The enclosure is reversible in design and does not have Left/Right-hand Options. Tray, however, has left/right options. For the Shower Tray, please refer to the attached PDF for more information.

Was this answer helpful?

Andy Asked :
Regarding Hudson Reed Apex Double Door Sliding Offset Quadrant Shower Enclosure 1200 x 900. Needing an LH tray with raiser kit as installing onto a solid floor. Can find the tray and raiser kit in step 3, but I can't find the location of the waste. Ideally, waste should be on the 900 straight sides, not the radius side. Can't see in pictures or documents where tray waste is located. Please can you advise? Incidentally, I have looked at Hudson Read tray NTP101, where the waste is ideally situated, but not sure whether this tray is compatible.

Answered By QS Team

The tray (NTP114) with waste is in the corner bottom right, looking at it.

Was this answer helpful?

Neil Asked :
The Hudson Reed Apex offset quadrant shower enclosure specification says it has a 538mm radius. Does this mean I have to buy a shower tray with a 530 mm radius, or can I use a 1200 mm X 800 mm offset quadrant tray with a 550 mm radius?

Answered By QS Team

The compatible trays are available in step 3 of the product. NTP112 (Left Hand) & NTP113 (Right hand) trays with a radius of 550mm are compatible.
