Nuie Melbourne 382 x 635mm Close Coupled White WC Set

Nuie Melbourne NCS150 Details

This fabulously elegant Melbourne Close Coupled WC with Cistern and Standard Close Seat will luxuriously redefine your bathroom. The durability of this impressive bathroom adornment is ensured by the high quality ceramic built. The seat is convenient to use. The white finishing adds to the visual impact. Nuie provides a 5 year guarantee on this close coupled toilet with cistern and seat.

Manufacturing code of this product: NCS150.
It comes in a white finish.
Overall Height: 748mm (74.8cm).
Weight: 24kg.
Download the Customer Data Sheet PDF File from the Additional Info Section.
For complete size details, please refer to the technical drawing.
Five years guarantee from Nuie against manufacturing defects.
Detail for pan:.
Height 380mm (38cm).
Projection from the wall: 635mm (63.5cm).
Bowl shape: Round.
Pan type: Open to wall.

Trap style: P trap.
Detail for cisterns:.
Width 382mm (38.2cm).
Operating type: Push-button.
Lever type: Plastic Chrome Plated.
Fully equipped cistern with water-saving dual flush mechanism.
Full Flush - 6 Ltrs and Half flush - 3 Ltrs.
Detail for seat:.
Shape: Round.
Material: Polypropylene.
It comes with plastic hinges.
Installation type: Top and bottom fix hinges.

Info / Size (mm)

Toilet
Width: 382 mm
Projection: 630 mm
Height: 748 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Melbourne
⤷ Toilet Design
: Open Back
⤷ Coating
: Without Coating
⤷ Colour
: White
⤷ Weight in kg
: 24
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Water Saving
: Yes
⤷ Pan Height
: 380
⤷ Toilet Overall Height
: 748
⤷ Projection (Depth)
: 635
⤷ Cistern Included
: Yes
⤷ Cistern Width
: 382
⤷ Flush Type
: Dual Flush

⤷ Full Flush Volume in litres
: 6
⤷ Half Flush Volume in litres
: 3
⤷ Flush Mechanism
: Push Button
⤷ Configuration
: Pan | Cistern | Seat
⤷ Seat Included
: Yes
⤷ Seat Type
: Standard
⤷ Seat Finish
: White
⤷ Compliance/Approvals/Standard
: CE | UKCA
⤷ Barcode
: 5060272820121
⤷ Bowl Shape
: Round
⤷ Product Type
: Closed Coupled
⤷ Base width
: 220
⤷ Base Depth (projection)
: 390
⤷ Outlet Diameter
: 102
⤷ Base to centre of outlet
: 180

Additional Info & Downloads

Download the Customer Data Sheet Pdf File

Total: £79.58 3-4 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Dual-Flush

A toilet with a flushing mechanism with two different buttons for flushing solid and liquid waste, thereby saving water.

UKCA Great Britain Mark

Merlyn enclosures now carry the UKCA mark, which stands for UK Conformance Assessment. This mark indicates that the product meets or exceeds GB-designated standards. The UKCA mark is now the standard labelling for products sold in Great Britain (England & Wales & Scotland).

Open-Back Toilet

Open-back toilets are a type of close-coupled toilet with a cistern attached to the back of the toilet, creating one single unit. In the open-back model, there is a space at the back between the toilet bowl and the wall to access pipework at the back, while the closed back does not have a gap.

Reviews & Ratings

By: Nicholas From : READING Overall Rating: Date: November 1, 2022 Good design at a good price

The design is good. The only letdown was the cheap seat which I replaced. As a novice buyer next I will check on the depth of the outlet from the wall. Because of the position of my standpipe, the cistern ended up away from the wall.
