Trojan Art Deco 1700 x 700mm Encapsulated Baseboard Bath White


RRP: £515.20


In-Stock In Stock

4.0 out of 5 4.0 out of 5

Based on 3 Ratings.

Shipping: FREE* Check Postcodes

Delivery in 8 Working Days Approx.
Key Features
  • Completes with leg set
  • Manufactured using a 4mm thick lucite acrylic sheet
  • Single-ended bath
  • Supplied with bath fittings as standard
  • Encapsulated baseboard routed and shaped to cover the full base of the bath, including around the plug hole
SKU Code: QS-V59917

MFC Code: B002397

Trojan Art B002397 Details

Trojan Art Deco Single Ended Bath with its octagonal inner area and bevelled rim will captivate you instantly. Crafted from high-grade acrylic and enhanced by a white finish, it is the right blend of beauty and utility. It features a generous depth and includes a leg set. Tested and approved according to prevailing standards of quality and safety, it is guaranteed for 25 years and offered at an excellent price at our online store. This brand new bath complements well with a bath shower mixer tap.

  • The manufacturing code of this product is B002397.
  • Supplied without tap holes.
  • Size [mm]: 1700mm x 695mm x 380mm [Length x Width x Height].
  • Size [cm]: 170cm x 69.5cm x 38cm [Length x Width x Height].
  • Overall Height: 510mm (51cm).
  • It comes in a fabulous white finish.
  • Material and product standards: EN263, EN198, CE EN 14516:2015 CL.1 PH, FSC TT-COC-003576.
  • Supplied with timber frame including 4mm plywood tap platform to offer rim support and fixing points for installation kits.
  • Water capacity: approx 180.
  • Waste and Overflow shown in the image are not included.
  • Front Panel and end panel available [Optional].
  • Bath waste [Optional].
  • Refer to the Technical drawing for detailed specifications.
  • Download the Fitting Instruction PDF File from the Additional Info Section.
  • 25 years of guarantee from Trojan.

Info / Size (mm)

  • Bath
  • Length: 1700 mm
  • Width: 695 mm
  • Depth: 400 mm

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Art Deco
  • ⤷ Interior Shape
  • : Rectangular
  • ⤷ Bath Type
  • : Standard
  • ⤷ Position of Drain
  • : Waste at Foot End
  • ⤷ Coating
  • : Without Coating
  • ⤷ External Length
  • : 1700
  • ⤷ External Width
  • : 700
  • ⤷ Tub Depth
  • : Min - 380 Max - 365
  • ⤷ Feets Included
  • : Yes
  • ⤷ Height Including Feet or Panel
  • : 510
  • ⤷ Front Panel Included
  • : Sold Separately
  • ⤷ End Panel Included
  • : Sold Separately
  • ⤷ Colour
  • : White
  • ⤷ Grips Included
  • : No
  • ⤷ Internal Bottom Length
  • : 1300
  • ⤷ Internal Bottom Width
  • : 480
  • ⤷ Internal Top Length
  • : 1510
  • ⤷ Internal Top Width
  • : 550
  • ⤷ Height of Rim
  • : 40
  • ⤷ Rim Width
  • : 115 75
  • ⤷ Slip Resistant
  • : No
  • ⤷ Shape
  • : Rectangular
  • ⤷ Capacity in litres
  • : 180
  • ⤷ Country of Origin
  • : UK
  • ⤷ Warranty/Guarantee
  • : 25 Years
  • ⤷ Material
  • : Lucite Acrylic Sheet
  • ⤷ No. of Bathers
  • : 1
  • ⤷ Theme
  • : Modern
  • ⤷ Waste Included
  • : Sold Separately
  • ⤷ Tap Holes
  • : Undrilled
  • ⤷ Barcode
  • : 5057199998897

Additional Info & Downloads

Customise Your Product

Front Panel
Front Panel

Choose your desire front panel from the option given below. Please Note image shown is for illustration purpose only

End Panel
End Panel

Optional End panel. Please note image shown is for illustration purpose only


High flow dedicated waste to flush out the wastewater. Please note the image shown is for illustration purpose only.

Total: £226.43 10-14 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Lucite Acrylic

Lucite Acrylic

It is a high-quality acrylic resin developed by DuPont in 1937 and is one of the top-quality materials available in today's market. It replaced glass as it is less breakable, offers high strength and resistance to UV rays, moisture and wind, and is easy to clean. It is also incredibly flexible and can create the best products.

FSC Certified

FSC Certified

Any product with this logo is made of wood from well-managed, sustainable forests. Its full form is certified by the Forest Stewardship Council. By buying such products, you are supporting responsible forestry.

Encapsulated Base Board

Encapsulated Base Board

The encapsulated base board has been coated with Glass Reinforced Plastic (GRP) to strengthen it and add a sealing quality to the construction while protecting it from water damage. It goes around the tub and the drain hole, supports the tub, and assists in sealing the underside from moisture.

Optional: Front Panel

Optional: Front Panel

A front bath panel is a decorative accessory that is used to cover the front-facing side of a bathtub for a neat and polished look. It also conceals plumbing and framework and comes in different sizes, textures and materials.

Optional End Panel

Optional End Panel

End Panels serve an aesthetic purpose to cap-off the exposed end of a bathtub and come in different sizes, shapes, designs, and finishes.

You've Selected which adds to a total of

Reviews & Ratings

Rate this Item.:

Hide All Reviews
From : TORQUAY Overall Rating: Date: May 18, 2018 Pretty design but needs 2 tweaks
Pros: Very pretty design, fits nicely with other Art Deco items such as a Duravit 1930s series toilet and Keswick Traditional Basin & Chrome Wash, as they all have an octagonal pattern. Value for money. Cons: The space for the taps needs to be twice as big. Cleaning behind the taps is hell and I'm sure my 'telephone shower' will end up scratching the tiles. The inclination for the back would have been more comfortable if it had been more gentle. I ended up buying a bath pillow in order to improve it (a bit).

Images Uploaded by the users: Images Uploaded by Richard Images Uploaded by Richard

Helpful? Thumbs Up Thumbs Down 3 of 3 People have found this Review useful
Value for Money
From : Withernsea Overall Rating: Date: March 30, 2021 exactly as advertised
A previous review claims that the tap plinth is not big enough. I also have a victorian shower tap, and when I drilled for the taps, there was plenty of room to position the taps; the bath is excellent value, and the quality with a 25yr guarantee exceeds its price; we are delighted with our choice and would highly recommend this product.
Helpful? Thumbs Up Thumbs Down 1 of 1 People have found this Review useful
Value for Money
From : Southall Overall Rating: Date: May 26, 2015 Decent
I love all things sober and understated. Took an instant liking to this bath which seems practical, durable and dependable.
Helpful? Thumbs Up Thumbs Down 1 of 1 People have found this Review useful
Value for Money

Questions & Answers

Submit Your Questions 3 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Stephen Asked :

Would you please tell me the thickness of the bath as it does not seem to be stated anywhere, unlike other baths?

Answered By QS Team Answered by the QS Technical Team

The bath is made from 4mm thick Lucite acrylic.

Was this answer helpful?
Alison Asked :

Can the bath be drilled for taps?

Answered By QS Team Answered by the QS Technical Team

This bath comes un-drilled for tapholes. However, Tap holes can be drilled as per your requirement by a professional plumber.

Was this answer helpful?
Rebekah Asked :

Does the Trojan Art deco bath have a reinforced base? What is the underside of the bath like?

Answered By QS Team Answered by the QS Technical Team

The Trojan Bath is made from Acrylic. The underneath of the bath is the same colour throughout.

Was this answer helpful?
Accepted Answer 1 Thumbs Down 1
