Jaquar Artize Thermatik-S Recessed Thermostatic Shower Valve

Jaquar Artize Thermatik-S Details

MFC: THK-CHR-691N

Jaquar Artize Thermatik-S Recessed Thermostatic Shower Valve - 2 Controls - Rectangular Trim.

Key Features

✔Warranty: 10-Year for the Chrome Finish and 5-Year for Other Finishes
✔Choice of Finishes: Chrome, Black-Chrome, Matt Black, Blush Gold PVD, Antique Bronze, Antique Copper, Gold Bright PVD and Gold Matt PVD

Choice of Outlets: 2 Outlet, 3 Outlet, 4 Outlet, 5 Outlet
Wall-Mounted Installation
Back Plate Size [mm]: 105 x 270mm [Width x Height]
Back Plate Size [cm]: 10.5 x 27cm [Width x Height]
Number of Handles: 2
Orientation: Vertical
Connections: 3/4-Inch BSP
Supplied with In-Wall Part
Protected Against Backflow
Ceramic Cartridge to Divert Water
Cartridges Made of High-Performance Thermostatic Polymer Materials that Meet the Global Standards for High and Low-Pressure
High Technology Thermoplastic Polymer Minimises Lime-Scale Build-Up
Standard Temperature Range: 15°C to 60°C [59-104°F]
Suitable for Medium Water Pressure Systems
Requires a Minimum of 0.5 Bar to a Maximum of 5.0 Bar Water Pressure
Refer to the Technical Diagram for Complete Technical Dimensions

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Thermatik-S
⤷ Colour
: Chrome
⤷ Shape
: Rectangular
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Inlet Connections
: 3/4-Inch BSP
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Handle Style
: Knob Handle
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 105

⤷ Backplate Height
: 270
⤷ Number of Handles
: 2
⤷ Orientation
: Portrait
⤷ Barcode
: 5057199986030
⤷ Product Type
: Shower Valve
⤷ Plumbing Option
: Concealed
⤷ Maximum Operating Pressure (Bar)
: 5.0
⤷ Concealed Body Included
: Yes
⤷ Cartridge Included
: Yes
⤷ Cartridge Type
: Ceramic Cartridge

Additional Info & Downloads

This item can also be found in:

Technical Images

Jaquar Artize Thermatik-S Recessed Thermostatic Shower Valve - 2 Controls - Rectangular Trim

2 Outlet

3 Outlet

4 Outlet

5 Outlet

£315.00

RRP: ~~£450.00~~

Stock Availablity: 5-7 Working Days Approx

QS Supplies

4 Features Included In This Product Explained

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Medium Water Pressure

Water systems operating at a pressure between 0.5 and 0.9 bar are considered medium pressure. Products usually come labelled if they are suitable for use in medium pressure.
