Armitage Shanks Edit Assist Comfort Height Back To Wall WC Pan

Armitage Shanks Edit Assist Details

MFC: S082501

Armitage Shanks Edit Assist Comfort Height Back To Wall WC Pan.

The Manufacturing Code of the Product is S082501
Size [mm]: 365 x 555 x 460mm [Width x Projection x Height]
Size [cm]: 36.5 x 55.5 x 46cm [Width x Projection x Height]
Weight: 32.70Kg
Combines Functionality with Design
Raised Height of the Bowl Offers Added Comfort to those with Extra Needs
Can be used in Ambulant Cubicles
Water Efficient
Flush Type: Washdown
Horizontal Outlet
Standards: Vitreous China to BS3402. WC Pan to BS EN 997 and BS EN 36
Refer to the Technical Drawing for Size Details

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Edit Assist
⤷ Colour
: White
⤷ Weight in kg
: 32.70
⤷ Warranty/Guarantee
: Lifetime
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Water Saving
: Yes
⤷ Pan Height
: 460
⤷ Projection (Depth)
: 555
⤷ Flush Type
: Washdown
⤷ Width
: 365
⤷ Outlet
: Horizontal

⤷ Comfort Height
: Yes
⤷ Configuration
: Bowl Only
⤷ Height
: 410
⤷ Fixings included
: Yes
⤷ Compliance/Approvals/Standard
: BS3402, BS EN 997, BS EN 36
⤷ Barcode
: 5017830545903
⤷ Bowl Shape
: Round
⤷ Base width
: 265
⤷ Base Depth (projection)
: 410
⤷ Pan fixing centres
: 140
⤷ Outlet Diameter
: 102
⤷ Base to centre of outlet
: 190

Armitage Shanks Edit Assist Comfort Height Back To Wall WC Pan

£349.61

RRP: ~~£607.32~~

Stock Availablity: 5-7 Working Days Approx

QS Supplies

2 Features Included In This Product Explained

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Vitreous-China Material

Vitreous china is an innovative glass-based enamel coating applied to porcelain. This glazed coating makes the base material durable, denser, and very glossy. When ceramics are coated with vitreous enamel, the resulting product is called vitreous china. This enamel is created by applying heat to powdered glass.
